Harman Kardon AVR 160 Service Manual

Level Ref. # Part Number
Description
Drawin
g
No
(
Value
)
Qt
y
....5 R612 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
....5 R701 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
....5 R702 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
....5 R703 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
....5 R711 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1
....5 R712 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1
....5 R713 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1
....5 R721 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
....5 R722 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1
....5 R731 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
....5 R735 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R741 CRD20TJ123T RES , CARBON 12K OHM 1/5W J 1
....5 R742 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
....5 R801 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1
....5 R802 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1
....5 R811 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
....5 R812 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
....5 R813 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
....5 R821 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
....5 R822 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
....5 R823 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
....5 R834 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1
....5 R835 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
....5 R836 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R901 CRD25TJ101T RES , CARBON (100 OHM) 1
....5 R902 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1
....5 R911 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1
....5 R912 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1
....5 R921 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
....5 R922 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
....5 R923 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R924 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1
....5 R925 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
....5 R926 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
....5 R931 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
....5 R932 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
....5 R933 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R934 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R935 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R936 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
....5 R941 CRD25TJ432T RES , CARBON(1/4W, 4.3K) 1
....5 R942 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1
....5 R943 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1
....5 R944 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1
....5 R951 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
....5 R953 CRD20TJ362T RES , CARBON 3.6K OHM 1/5W J 1
....5 R954 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
....5 S311 CST1A024ZT SW , TACT 1
....5 S312 CST1A024ZT SW , TACT 1
....5 S313 CST1A024ZT SW , TACT 1
....5 S314 CST1A024ZT SW , TACT 1
....5 S315 CST1A024ZT SW , TACT 1
....5 S316 CST1A024ZT SW , TACT 1
....5 S317 CST1A024ZT SW , TACT 1
....5 S318 CST1A024ZT SW , TACT 1
....5 S319 CST1A024ZT SW , TACT 1
....5 S320 CST1A024ZT SW , TACT 1
....5 S321 CST1A024ZT SW , TACT 1
....5 S322 CST1A024ZT SW , TACT 1
....5 S323 CST1A024ZT SW , TACT 1
....5 S330 CST1A024ZT SW , TACT 1
...4 BK71 CMD1A572 BRACKET , FIP 1
...4 BK72 CMD1A572 BRACKET , FIP 1
...4 BN51 CWB1C907250BM001 SHIELD WIRE ASS'Y (2.5mm, 250mm, 7pin) 1
...4 BN52 CWB1C903400BM001 SHIELD WIRE ASS'Y (2.5mm, 400mm, 3pin) 1
...4 BN61 CJP12GB143ZB PIN HEADER , DIP SOCKET(12PIN, 2.54mm, ANGLE) 1
...4 BN73 CJP06GB143ZB FEMALE HEADER(6P, 2.54mm) 1
...4 BN74 CWB1C905120BM WIRE ASS'Y 1
...4 CN61 CJP12GA239ZB PIN HEADER(12P, 2.54mm), STRAIGHT TYPE 1
...4 CN71 CJP05GB03ZY WAFER , ANGLE (2.5mm) 1
...4 CN72 CJP31GA41ZM WAFER
(
1.25MM, CARD CABLE, STRAIGHT 3
1
MOLEX 52045-**45 1
...4 CN73 CJP06GB142ZB PIN HEADER(6P, 2.54mm) 1
...4 CN74 CJP05GB03ZY WAFER , ANGLE (2.5mm) 1
...4 C411 CCEA1JH101E CAP , ELECT 100UF 63V 1
...4 D101 CVD1L0345W31BOCT201W L.E.D , WHITE 1
...4 D102 CVD30ASOGCAA-S7 L.E.D , ORANGE T0L-30ASOGCAA-S7 1
...4 D201 CVD1L0345W31BOCT201W L.E.D , WHITE 1
...4 D202 CVD1L0345W31BOCT201W L.E.D , WHITE 1
...4 D203 CVD1L0345W31BOCT201W L.E.D , WHITE 1
FRONT PCB ASS
Y
harman/kardon
AVR 160/230 Service Manual
16 of 116

Harman Kardon AVR 160 Specifications

General

Receiver type	Surround
RMS rated power	35 W
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	110 W
Digital audio coaxial out	1
Digital audio optical in	3
Connectivity technology	Wired
Speakers connectivity type	-
Ethernet LAN	No
Supported radio bands	AM, FM
Preset stations quantity	30
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	10500 g
