Harman Kardon AVR 160 Service Manual

Level Ref. # Part Number
Description
Drawin
g
No
(
Value
)
Qt
y
...4 ET63 CMC2A325 PLATE , EARTH AVR155 1
...4 ET64 CMC4A111 PLATE , EARTH 1
...4 FB13 KLZ9H001Z BEAD , CORE 1
...4 FB14 KLZ9H001Z BEAD , CORE 1
...4 FB15 KLZ9H001Z BEAD , CORE 1
...4 F1 CFL162BD01GINK V.F.D 162-BD-01GINK 1
...4 IC11 HVI74HCU04AFNG I.C , INVERTER (TOSHIBA) TC74HCU04AFNG
(
TOSHI
B
1
...4 IC12 HRVNJL34H380A SENSOR , REMOCON (JRC) 1
...4 IC13 HVI74ACT04MTR I.C , HEX (ST) 1
...4 IC14 HVINJM2068MTE1 I.C , OP AMP (JRC) NJM2068M-TE1 1
...4 IC15 HVINJM4556AL I.C , HEADPHONE (JRC) NJM4556AL 1
...4 JK51 CJJ9X006Z JACK , USB STRAIGHT(BLACK) U250FD004BY 1
...4 JK52 CJJ4S028Y JACK , BOARD (3P SILVER) 1
...4 JK61 CJJ4M041Y JACK , BOARD (COAX) 1
...4 JK62 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1
...4 JK63 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE) 1
...4 RL91 CSL4A016ZU RELAY , 12V 2C2P BC3-12H 1
...4 VR74 CSR2A037Z ENCODER 1
Level
Ref. # Part Number
Description
Drawin
g
No
(
Value
)
Qt
y
..3 COP12170E AVR160 MAIN PCB ASS'
Y
1
...4 CIP12170E AVR160 MAIN PCB AUTO ASS'Y 1
....5 CUP12170X PCB , MAIN AVR1600 (330X247, FR1) 1
....5 C501 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C502 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C503 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C504 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C505 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C506 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1
....5 C507 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1
....5 C508 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1
....5 C509 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1
....5 C510 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1
....5 C561 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C562 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C563 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C564 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C565 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C566 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C567 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C568 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C569 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C570 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C571 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C572 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C573 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C574 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C575 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C601 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C602 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C603 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C604 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C605 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C606 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C607 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C608 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C609 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C610 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C681 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C682 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C683 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C684 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C685 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C726 CCKT1H221KB CAP , CERAMIC 220PF 50V K 1
....5 C801 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C802 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C803 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C804 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C805 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C806 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C811 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C812 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C813 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C814 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C815 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1
....5 C816 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1
....5 C817 CCEA1HH100
T
CAP , ELECT 10UF 50
V
1
FRONT PCB ASS
Y
MAIN PCB ASS
Y
harman/kardon
AVR 160/230 Service Manual
17 of 116

Harman Kardon AVR 160 Specifications

General

Receiver type	Surround
RMS rated power	35 W
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	110 W
Digital audio coaxial out	1
Digital audio optical in	3
Connectivity technology	Wired
Speakers connectivity type	-
Ethernet LAN	No
Supported radio bands	AM, FM
Preset stations quantity	30
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	10500 g
