Harman Kardon AVR 430

AVR430/230 FRONT PCB 1/3
POS PART NAME PART NUMBER
C100 CCCFMIC 820P0F +10% -10% 50.0V X7R CZKII0821BC
C101 CCCFMIC 820P0F +10% -10% 50.0V X7R CZKII0821BC
C102 CCCFMIC 100N0F +80% -20% 16.0V Y5V CZZFI0104BF
C103 CE 47U0F +20% 16.0V 85C CEHFC0476DH
C110 CCCFMIC 100N0F +80% -20% 16.0V Y5V CZZFI0104BF
C111 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE
C112 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE
C113 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE
C115 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE
C116 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE
C118 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE
C119 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE
C120 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE
C121 CCCFMIC 100P0F +5% -5% 50.0V NP0 0603 CZJII0101BE
C122 CCCFMIC 100N0F +80% -20% 16.0V Y5V CZZFI0104BF
C123 CC 100N0F +80% -20% 50.0V F CCZID0104NA
C129 CPF 47N0F +10% 100.0V CPIKC0473NN
C130 CPF 47N0F +10% 100.0V CPIKC0473NN
C131 CE 47U0F +20% 16.0V 85C CEHFC0476DH
C132 CCCFMIC 100N0F +80% -20% 16.0V Y5V CZZFI0104BF
C200 CCCFMIC 100N0F +80% -20% 16.0V Y5V CZZFI0104BF
C201 CCCFMIC 100N0F +80% -20% 16.0V Y5V CZZFI0104BF
C220 CCCFMIC 22N0F +10% -10% 50.0V X7R 0603 CZKII0223BC
C221 CCCFMIC 22N0F +10% -10% 50.0V X7R 0603 CZKII0223BC
C601 CE 100U0F +20% 10.0V 5X11 85C CEHEC0107NN
CA11 CPPMX 100N0F +20% -20% CFMVA0104NN
D100 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D101 D-SLP 1N4148 100.0V 150E-3A H01-DG1N04148NB
D102 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D103 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D104 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D105 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D200 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D201 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D202 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D203 D-SLP 1SS355 35.0V 225MI0A H01-DS1S50094NB-A
D703 D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 H01-DL30B2015AA-A
D704 D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 H01-DL30B2015AA-A
D705 D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 H01-DL30B2015AA-A
D706 D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 H01-DL30B2015AA-A
D707 D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 H01-DL30B2015AA-A
D708 D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 H01-DL30B2015AA-A
D709 D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 H01-DL30B2015AA-A
D710 D-LEM 30B3-20-15 GaN SUPER BLUE WATER CLEAR 15 H01-DL30B2015AA-A
D800 D-LEM BLUE/AMBER 3PIE RD RND CL H01-DL3BA05V0BA
DP10 FL HCA-18LL03 H01-VDHCA18LL03
IC101 IC CMOS BU4094BF SOP16 H01-ICBU4094BD3
J139 LF 47U0H +10% 5.8 OHM 500MI0A H01-LAINB0470CR
J156 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J157 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J301 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J302 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J303 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J503 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J504 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J505 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J506 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J902 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
J903 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
JC502 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
JD503 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
JR901 RMGCFMIC 0 OHM +0% 62MI5W RS3AD0000NA
L100 LF 4U7H +10% 1.7 OHM 190.0A H01-LAINB047ACR
N101~P101 WIRECONASY DL 2.0MM 03P 90MM ANG UL1007 RIBBON 26 1 B2011HR2 H01-WG03AB80900
N102 WIRECONASY DL 2.0MM 04P 220MM UL1007 RIBBON 26 1 H01-WG04SB82200
N103 WIRECONASY DL 2.0MM 6P 510MM UL1533 SHIELD 26 1 H01-WS6265105EN
