Harman Kardon AVR 430

AVR430/230 FRONT PCB 2/3
POS PART NAME PART NUMBER
N107 WIRECONASY DL 2.0MM 04P 480MM UL1533 SHIELD 26 1 2/2 H01-WS4264822EN
N110 WIRECONASY DL 2.5MM 07P 400MM UL1007 RIBBON 24 1 H01-WG07SD84000
NJ80 CON PHONO SCKT RCA-313P 3 PINS H01-SORA3313PNN
NJ81 JACK S-VIDEO 1P C40160261N H01-SORA8OSC5N8
NS199 CON MAINS INLET A/C INLET 7014-NGP H01-SOXA27014NN
P103 CONN 1.25MM 23 FE ANG WH GF120-23S-LS 2794 A6 H01-WN23AI000WH
P105 CONN 1.25MM 19 FE ANG WH GF120-19S-LS 2794 A6 H01-WN19AI00000
P120 CONN 2.0MM 11P MA ST NAT MOLEX 35336-1110 0 0 H01-WN11SB00000
P121 CONN 2.0MM 11 MA R NAT SOCKET MOLEX 35237-1110 0 0 H01-WN11AB00000
P122 CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0 H01-WN19SB00000
P123 CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910 0 0 H01-WN19AB00000
P199 CON 3.96MM PITCH HEADER 2 POS MOLEX 35328-0210 H01-WN02SE00000
Q100 TR-SLPLF MPSA56 Y P -500MI0A -300V H01-TRMPSA56YNA
Q101 TR-SLPLF MPSA56 Y P -500MI0A -300V H01-TRMPSA56YNA
Q102 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM H01-TRDTC114YNI
Q103 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM H01-TRDTC114YNI
Q800 TR-SLPSWA KTD1304 N 20V 300MI0A SOT-23 H01-TRKTD1304ND
Q805 TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM H01-TRDTC114YNI
R1 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R100 RMGCFMIC 68K0 OHM +5% 62MI5W RS3AD0683NA
R101 RMGCFMIC 68K0 OHM +5% 62MI5W RS3AD0683NA
R102 RMGCFMIC 4K7 OHM +5% 62MI5W RS3AD0472NA
R103 RMGCFMIC 10R0 OHM +5% 62MI5W RS3AD0100NA
R104 RMGCFMIC 47K0 OHM +5% 62MI5W RS3AD0473NA
R109 RMGCFMIC 220R0 OHM +5% 62MI5W RS3AD0221NA
R110 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R119 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R120 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R121 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R122 RMGCFMIC 470R0 OHM +5% 62MI5W RS3AD0471NA
R134 RMGCFMIC 220R0 OHM +5% 62MI5W RS3AD0221NA
R136 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R160 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R161 RMGCFMIC 100R0 OHM +5% 62MI5W RS3AD0101NA
R162 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R163 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R164 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R165 RCF 10K0 OHM +5% 250MI0W RC3DI0103IN
R166 RCF 10K0 OHM +5% 250MI0W RC3DI0103IN
R167 RCF 10K0 OHM +5% 250MI0W RC3DI0103IN
R2 RMGCFMIC 100K0 OHM +5% 62MI5W RS3AD0104NA-A
R201 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R202 RMGCFMIC 1K2 OHM +5% 62MI5W RS3AD0122NA
R203 RMGCFMIC 1K5 OHM +5% 62MI5W RS3AD0152NA-A
R204 RMGCFMIC 2K2 OHM +5% 62MI5W RS3AD0222NA
R205 RMGCFMIC 2K7 OHM +5% 62MI5W RS3AD0272NA
R206 RMGCFMIC 3K3 OHM +5% 62MI5W RS3AD0332NA
R207 RMGCFMIC 5K6 OHM +5% 62MI5W RS3AD0562NA
R208 RMGCFMIC 8K2 OHM +5% 62MI5W RS3AD0822NA
R209 RMGCFMIC 18K0 OHM +5% 62MI5W RS3AD0183NA-A
R211 RMGCFMIC 1K0 OHM +5% 62MI5W RS3AD0102NA
R212 RMGCFMIC 1K2 OHM +5% 62MI5W RS3AD0122NA
R213 RMGCFMIC 1K5 OHM +5% 62MI5W RS3AD0152NA-A
R214 RMGCFMIC 2K2 OHM +5% 62MI5W RS3AD0222NA
R215 RMGCFMIC 2K7 OHM +5% 62MI5W RS3AD0272NA
R216 RMGCFMIC 3K3 OHM +5% 62MI5W RS3AD0332NA
R217 RMGCFMIC 5K6 OHM +5% 62MI5W RS3AD0562NA
R218 RMGCFMIC 8K2 OHM +5% 62MI5W RS3AD0822NA
R219 RMGCFMIC 18K0 OHM +5% 62MI5W RS3AD0183NA-A
R700 RCF 330R0 OHM +5% 250MI0W RC3DI0331IN
R701 RCF 330R0 OHM +5% 250MI0W RC3DI0331IN
R702 RCF 330R0 OHM +5% 250MI0W RC3DI0331IN
R703 RCF 330R0 OHM +5% 250MI0W RC3DI0331IN
R800 RMGCFMIC 680R0 OHM +5% 62MI5W RS3AD0681NA
R801 RMGCFMIC 680R0 OHM +5% 62MI5W RS3AD0681NA
R802 RCF 220R0 OHM +5% 250MI0W RC3DI0221IN
