Harman Kardon AVR 4500 Service Manual

PART NO
: 55261880
TITEL
: AC EMBD IMA DSP BD AVR4500
Pos
Tocom#
Pkg
M/B
St
Qty
Unit
SName
010
55262030
M
SO
1
PCE
AC ESABD IAU DSP BD AVR4500
020
55188910
X
ud
1
PCE
AC SCHEMATIC DSP BD AVR520 OEM
040
20290150
B
so
0.015
KG
SOLDER BAR 52SN/45PB/3SB BAR
041
15481260
B
so
0.015
L
SLDC FLUX LRES FOAM SM32DHT-2
C504
20269180
AM
B
so
1
PCE
CE 1MI0F +20% 6.3V 85C
C505
20269180
AM
B
so
1
PCE
CE 1MI0F +20% 6.3V 85C
C506
20269180
AM
B
so
1
PCE
CE 1MI0F +20% 6.3V 85C
CN102
55174670
B
so
1
PCE
CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910 0 0
CN103
55174660
B
so
1
PCE
CONN 2.0MM 17 MA R NAT SOCKET MOLEX 35237-1710 0 0
CN105
55175860
NR
B
so
1
PCE
WIRECONASY UNIQUE 5P 480MM UL1007 PVC DISCRETE 26 1
CN106
55191240
NR
B
so
1
PCE
WIRECONASY UNIQUE 3P 500MM UL1007 PVC DISCRETE 26 1
CP101
55123390
B
so
1
PCE
CONN 2.0MM 5 MA R NAT LW2003P05 0 0
CP102
55123390
B
so
1
PCE
CONN 2.0MM 5 MA R NAT LW2003P05 0 0
JAC1
55175240
B
so
1
PCE
CON PHONO SCKT RCA 1P W/GND JE010003MG
JAC2
55125430
NR
B
so
1
PCE
D-LEM TORX178B RD RND CL
JK101
55125430
NR
B
so
1
PCE
D-LEM TORX178B RD RND CL
JK102
55125430
NR
B
so
1
PCE
D-LEM TORX178B RD RND CL
JK103
55125440
NR
B
so
1
PCE
D-LEM TOTX178B RD RND CL
JK105
55191600
B
so
1
PCE
CON PHONO SCKT RCA 2P W/GNDCAP JW-1502SN OO
JK106
55175950
B
so
1
PCE
CON PHONO SCKT RCA 1P W/GND JE010003MN
OSC101
55126130
NR
B
so
1
PCE
VCXO 12M288 HZ +50 PPM -50 PPM 0 OHM
OSC102
55126140
NR
B
so
1
PCE
CRESONATOR 10M0 HZ 25.0 OHM 0F
RY101
55179930
NR
B
so
1
PCE
RELAYPWR 5.0V 166.0OHM 1.0A 24.0V
SHILD
55182550
B
ud
1
PCE
AC PUN SHIELD DIGITAL ET
T101
55176540
NR
B
so
1
PCE
TFPULSE TRANSFORMER 110UH FP-110 FERRIT MAGNET
T102
55176550
NR
B
so
1
PCE
TFPULSE TRANSFORMER 110UH FP-120 FERRIT MAGNET
W1
55180120
NR
B
so
1
PCE
WIRECONASY UNIQUE 1P 100MM UL1007 PVC DISCRETE 18 1
PART NO
: 55262030
TITEL
: AC ESABD IAU DSP BD AVR4500
Pos
Tocom#
Pkg
M/B
St
Qty
Unit
SName
040
55182530
B
po
1
PCE
AC PCB DSP AVR520 DUAL LAYERS
C132
20266570
71
B
so
1
PCE
CPF 68N0F +10% 50.0V
C301
15002130
30
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C501
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C502
20268850
30
B
so
1
PCE
CE 2U2F +20% 50.0V 85C
C507
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C508
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C509
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C510
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C511
20267830
30
B
so
1
PCE
CE 47U0F +20% 16.0V 85C
C512
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C513
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C514
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C515
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C516
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C517
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C518
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C519
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C520
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C521
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C522
20267830
30
B
so
1
PCE
CE 47U0F +20% 16.0V 85C
C523
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C524
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C525
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
