Harman Kardon AVR 4500 Service Manual

C526
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C527
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C528
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C529
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C530
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C531
20267830
30
B
so
1
PCE
CE 47U0F +20% 16.0V 85C
C532
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C533
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C534
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C535
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C536
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C537
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C538
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C539
20268840
30
B
so
1
PCE
CE 1U0F +20% 50.0V 85C
C540
20267830
30
B
so
1
PCE
CE 47U0F +20% 16.0V 85C
C541
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C542
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C543
20269110
30
B
so
1
PCE
CE 330U0F +20% 6.3V 85C
C544
20269110
30
B
so
1
PCE
CE 330U0F +20% 6.3V 85C
C545
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C546
20252560
30
B
so
1
PCE
CE 220U0F +20% 6.3V 85C
C547
10121000
39
B
so
1
PCE
CE 10U0F +20% 16.0V 85C
C548
20269070
30
B
so
1
PCE
CE 100U0F +20% 25.0V 85C
C549
20269070
30
B
so
1
PCE
CE 100U0F +20% 25.0V 85C
PART NO
: 55262160
TITEL
: AC ESABD SMD TOP DSP BD AVR4500
Pos
Tocom#
Pkg
M/B
St
Qty
Unit
SName
BD10
55126690
50
B
so
1
PCE
FBEAD SURFACE MT 2500OHM FCM2012H-252T02
BD13
55126690
50
B
so
1
PCE
FBEAD SURFACE MT 2500OHM FCM2012H-252T02
BD18
55126690
50
B
so
1
PCE
FBEAD SURFACE MT 2500OHM FCM2012H-252T02
BD19
55126650
50
B
so
1
PCE
FBEAD SURFACE MT 300OHM FCM2012V-301T07
BD22
55126650
50
B
so
1
PCE
FBEAD SURFACE MT 300OHM FCM2012V-301T07
BD23
55126650
50
B
so
1
PCE
FBEAD SURFACE MT 300OHM FCM2012V-301T07
BD24
55126690
50
B
so
1
PCE
FBEAD SURFACE MT 2500OHM FCM2012H-252T02
BD25
55126690
50
B
so
1
PCE
FBEAD SURFACE MT 2500OHM FCM2012H-252T02
C100
20288040
91
B
so
1
PCE
CCCFMIC 100N0F +80% -20% 16.0V Y5V
C101
20506640
91
B
so
1
PCE
CCCFMIC 220P0F +5% -5% 50.0V NP0
C102
20678070
91
B
so
1
PCE
CCCFMIC 330P0F +5% -5% 50.0V NP0
C105
20678070
91
B
so
1
PCE
CCCFMIC 330P0F +5% -5% 50.0V NP0
C107
20288060
91
B
so
1
PCE
CCCFMIC 220N0F +80% -20% 16.0V Y5V
C110
20288040
91
B
so
1
PCE
CCCFMIC 100N0F +80% -20% 16.0V Y5V
C113
20506520
91
B
so
1
PCE
CCCFMIC 22P0F +5% -5% 50.0V NP0
C114
10138960
91
B
so
1
PCE
CCCFMIC 10N0F +10% -10% 50.0V X7R
C115
20506520
91
B
so
1
PCE
CCCFMIC 22P0F +5% -5% 50.0V NP0
C116
10138960
91
B
so
1
PCE
CCCFMIC 10N0F +10% -10% 50.0V X7R
C119
20288040
91
B
so
1
PCE
CCCFMIC 100N0F +80% -20% 16.0V Y5V
C120
20288040
91
B
so
1
PCE
CCCFMIC 100N0F +80% -20% 16.0V Y5V
C123
20288040
91
B
so
1
PCE
CCCFMIC 100N0F +80% -20% 16.0V Y5V
C124
20506520
91
B
so
1
PCE
CCCFMIC 22P0F +5% -5% 50.0V NP0
C125
10138960
91
B
so
1
PCE
CCCFMIC 10N0F +10% -10% 50.0V X7R
C135
20288040
91
B
so
1
PCE
CCCFMIC 100N0F +80% -20% 16.0V Y5V
C137
20288040
91
B
so
1
PCE
CCCFMIC 100N0F +80% -20% 16.0V Y5V
C138
20288040
91
B
so
1
PCE
CCCFMIC 100N0F +80% -20% 16.0V Y5V
C145
10138670
91
B
so
1
PCE
CCCFMIC 3N3F +10% -10% 50.0V X7R
C146
10138670
91
B
so
1
PCE
CCCFMIC 3N3F +10% -10% 50.0V X7R
C147
10138670
91
B
so
1
PCE
CCCFMIC 3N3F +10% -10% 50.0V X7R
C148
10138670
91
B
so
1
PCE
CCCFMIC 3N3F +10% -10% 50.0V X7R
C149
10138390
91
B
so
1
PCE
CCCFMIC 560P0F +10% -10% 50.0V X7R
