System Configuration
15
ENGLISH
Once the speakers have been placed in
the room and connected, the final step is
to enter the configuration information
and balance the speaker output levels.
Before proceeding further this is a good
time to review the installation section of
the manual to make certain that all
connections are properly made.
System Settings
1. Plug the unit into an AC wall outlet
and press the Power button on either
the front panel * or the remote b.
Note that the ring surrounding the front
panel switch will turn green, and the
front panel display will illuminate.
2. Check to see that the unit is configured
to the video broadcast standard in use in
your country by pressing and holding the
OSD button on the front panel ) for
more than three seconds. The front panel
display will indicate the current setting. If
the setting is not correct, if f.e. your
picture is only black and white, press the
button again until the correct standard
(PAL, SECAM or NTSC) is displayed.
3. Turn on the TV connected to the
receiver. Select the appropriate video
input on the TV.
NOTE: Although the unit will switch “S”
video signals, the on screen menus
control system is NOT visible on the S
video output.
4. Press any of the navigational arrow
buttons or the SELECT r button on
the remote to bring the MAIN MENU up
on your video screen.
(Figure #1)
5. Press the ¤ button three times until
the on screen
>
cursor is pointing to
SET UP MENU. Press SELECT r.
6. At the SET UP MENU (Figure #2),
set the Center Channel Mode. The on
screen
>
cursor will already point toward
this option when you select the menu.
Press the ‹ or › buttons q to choose
one of these center channel options by
moving the cursor:
LARGE: Choose this option if you
are using large size full range center
channel speaker.
SMALL: Choose this option if the
center speaker is small sized.
NONE:Choose this option if you are
not using a center channel speaker.
7. When you have made a center channel
selection, press ¤ q to move to the
next option. Note that the
>
cursor
should point to SET UP LOCK.
8. This option enables you to lock the
configuration settings. This makes it
difficult for someone to inadvertently
change the settings by causing the
word LOC K to appear at the top of the
SET UP MENU. Before any further
changes can be made, the user must first
go to the SET UP MENU and unlock
the system. Press the ‹ or › buttons q
to choose one of these options:
LOC K: Choose this option to lock the
settings as described above.
UNLOCK: Choose this option to
unlock the settings and enable them
to be changed without going to this
menu.
