Harman Kardon AVR 70 User Manual

AVR70
AM/FM CD
T-MON
VCR2
T·2 TV LD VCR1 Aux DISP OSD Delay
Bass
ModeClear
PhonesPower
Memo
Treble Balance
Volume
P•SET P•Scan TUNE
AUX
VIDEO
RLMaxMinMaxMin
L–AUDIO–R
MuteMODE
RDS
DISP. AF PTY.
VISUAL
SIGNAL
LEVEL
CH
TV LD VCR 12 AUX
TEST
STEREO PRO
•
LOGIC MOVIE HALL MATRIX
MEMO AUTO TUNED STEREO
dB
kHz
MHz
3-LOGIC AUTO MEMO P-SCAN DISP
12
3
(* Ó Ô  ÙÛÚÒ ı ˆ ˜
4 5 6 9 ) !@ # $ %
^
&
87
VISUAL
SIGNAL
LEVEL
CH
TV LD VCR 12 AUX
TEST
STEREO PRO
•
LOGIC MOVIE HALL MATRIX
MEMO AUTO TUNED STEREO
dB
kHz
MHz
3-LOGIC AUTO MEMO P-SCAN DISP
¡
›
™£¢∞ §
¶
•
ª‚⁄¤
‹
Front Panel
Information Display
¡ “Visual” Indicators
™ Test
£ Memo
¢ Auto
∞ Tuned
§ Stereo
¶ Volume Indication
• Tuner Frequency Indication
ª Main Information Display
‚ Display
⁄ P-Scan
¤ Auto Memo
‹ Mode Statue
› Signal Level Indication
1 Information display
2 Remote Sensor Window
3 AM/FM Tuner Mode Selection
4 CD
5 Tape1/Monitor
6 Tape2
7 Video Sources
8 Aux
9 Display
) OSD (On Screen Display)
! Delay
@ Mode
# Preset Tuning
$ P-Scan
% Tune
^ Mute
& Volume Control
* Power
( Headphone Jack
Ó Memo
Ô Clear
 FM Mode
Ò RDS Display
Ú RDS Alternate Frequency
Û RDS Programme Type
Ù Bass
ı Treble
ˆ Balance
˜ Front Panel Inputs
AVR70 engelsk manual 11/01/98 11:57 Side 3

Harman Kardon AVR 70 Specifications

General

Impedance	75 Ω
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.1 %
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	3
Line-in	Yes
Audio (L/R) in	1
Digital audio optical in	2
Connectivity technology	Wired
Speakers connectivity type	-
Ethernet LAN	No
AM band range	520 - 1720 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Volume control	Digital
Apple docking compatibility	Not supported
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	280 W
Cables included	AC

Weight and Dimensions

Depth	330 mm
Width	440 mm
Height	125 mm
Weight	9100 g
