Harman Kardon AVR 7550HD

NO Designator AVR7550HD US AVR755 EU Description QTY
if applicable Part Number Part Number
1 CKC1A184S60 COVER TOP 1
2 CMH1A285 HOLDER , VFD AVR7550HD 1
3 CHG1A394 RUBBER , SENSOR AVR7550HD 1
4 CMC1A335 SHIELD , IR AVR7550HD 1
5 CBT1A1066H61 BUTTON , 9KEY AVR7550HD 1
6 CBT1A1070B24 BUTTON , STANDBY AVR7550HD 1
7 CGL1A270 INDICATOR , STANDBY 1
8 SW3550 CSH1A001ZV SWITCH 1
9 CBC1A162H61Z BUTTON , POWER AVR7550HD 1
10 CDG1A026 GEAR , DAMPER(DP120) 1
11 CMH1A284 HOLDER , MAGNET AVR7550HD 2
12 CJC1A009 MAGNET , AVR7550HD(10X10X4t) 2
13 CDF1A020 SHAFT , DOOR AVR7550HD 4
14 CGW1A448R4ZB24 CGW1A448R4YB24 BODY , FRONT AVR7550HD 1
15 CHG1A385 RUBBER , DOOR AVR7550HD 2
16 CMZ1A129Z FILTER , VFD AVR7550HD 1
17 CGU1A416A25Z WINDOW , FIP AVR7550HD 1
18 CGB1A210Z CGB1A196Z BADGE Model Name 1
19 CGB1A158Y BADGE , FRONT HARMAN/KARDON 1
20 CGX1A405C66Z VENNER , AL FRONT AVR7550HD 1
21 CGX1A404C66Z VENNER , AL DOOR AVR7550HD 1
22 CMD1A646 BRACKET , MAGNET AVR7550HD 2
23 CGR1A488B24 DOOR , UNDER 1
24 CGX1A403Z PLATE , DOOR AVR7550HD 1
25 CGU1A318 ORNAMENT , VOLUME AVR255 1
26 CGK1A131C63 KNOB , COVER AVR7550HD 1
27 CMH1A214 HOLDER , VOLUME 1
28 CGL1A222 INDICATOR , VOLUME 1
29 CMD1A647 BRACKET , SHAFT HINGE L AVR7550HD 2
30 CMD1A648 BRACKET , SHAFT HINGE R AVR7550HD 2
31 CBT1A1067H61Z BUTTON , 4 DIRECTION AVR7550HD 1
32 CBT1A1069 RETAINER, OK BUTTON AVR7550HD 1
33 JA3503 HJJ2E021Z JACK , HEADPHONE 1
34 JA3507 CJJ9X005Z JACK , USB(ANGLE, AU PLATE, YKF45-0041N) 1
35 JA3504 HJSTORX177L MODULE , OPTICAL(RX) 1
36 JA3505 CJJ4M061Z JACK , RCA (1P, 107BAG, OR, AU PL) 1
37 JA3502 CJJ9M006Z JACK , DIN (1P, S-VHS, 434A, AU PL) 1
38 JA3501 CJJ4S046Z JACK , RCA (3P, 303, YL WH RD, AU) 1
39 JA3506 HJJ2E017Z JACK 1
40 CMC1A332 SHIELD , DIGITAL AVR7550HD 1
41 CBT1A1068H61Z BUTTON , OK AVR7550HD 1
42 CMC1A334 PLATE , SPRING GND(0.2T) AVR7550HD 3
43 CMD1A649 CHASSIS , FRONT AVR7550HD 1
44 CMD1A650 BRACKET , TRANS BOTTOM AVR7550HD 1
45 CMD1A660 BRACKET , HEAT SINK AVR7550HD 5
46 CMD1A657 BRACKET , POSISTOR AVR7550HD 2
47 CMY1A292 HEAT SINK , SURR AMP AVR7550HD 1
48 CLT5W031ZU TRANS , MAIN POWER AVR7550HD (UL, 120V 60Hz) 1
49 CMY3A239 HEAT SINK 1
50 CDF1A022 STAND OFF(HEX M4x87.4H) AVR7550HD 1
51 CMY2A294 HEAT SINK , DIODE AVR7550HD 1
52 JA3000 CJJ8A007ZD JACK , AC INLET (2P, AC054S020A,10A, 250V) 1
53 CMD1A656 BRACKET , AC INLET AVR7550HD 2
54 JA3001 KJJ7A013Z OUTLET , AC 1 PIN USA 1
55 CMD1A659 BRACKET , VIDEO AVR7550HD 1
56 CMY1A291 HEAT SINK , MAIN AVR7550HD 1
57 CMD1A645 BRACKET , ETHER AVR7550HD 1
58 CMD1A653 BRACKET , FAN REAR AVR7550HD 1
59 JA901 CJJ5R014Z TERMINAL , SPEAKER (6P, GN/BN/TA, SCREW , AU) 1
60 JA2006 CJJ9H004Z JACK , HDMI GOLD 1
60 JA2007 CJJ9H004Z JACK , HDMI GOLD 1
60 JA2008 CJJ9H004Z JACK , HDMI GOLD 1
60 JA2009 CJJ9H004Z JACK , HDMI GOLD 1
60 JA2010 CJJ9H004Z JACK , HDMI GOLD 1
61 CHG1A407 RUBBER 20X15X9t 2
62 JA2000 CJJ2D008Z JACK , STEREO 1
62 JA2001 CJJ2D008Z JACK , STEREO 1
62 JA2002 CJJ2D008Z JACK , STEREO 1
62 JA2003 CJJ2D008Z JACK , STEREO 1
AVR7550HD Exploded View Part list
