Harman Kardon AVR 7550HD

Ref. Designator Part Number Description Qty
FRONT PCB ASSY
COP12040B
R3520 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
R3521 CRD20TJ561T RES , CARBON 560 OHM 1/5W J 1
R3523 CRD20TJ681T RES , CARBON 680 OHM 1/5W J 1
R3524 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R3540 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1
R3541 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1
R3543 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J 1
R3545 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1
R3560 CRD20TJ2R2T RES , CARBON 2.2 OHM 1/5W J 1
R3561 CRD20TJ2R2T RES , CARBON 2.2 OHM 1/5W J 1
Miscellaneous
S3501 CST1A024ZT SW , TACT 1
S3502 CST1A024ZT SW , TACT 1
S3503 CST1A024ZT SW , TACT 1
S3504 CST1A024ZT SW , TACT 1
S3505 CST1A024ZT SW , TACT 1
S3506 CST1A024ZT SW , TACT 1
S3507 CST1A024ZT SW , TACT 1
S3508 CST1A024ZT SW , TACT 1
S3509 CST1A024ZT SW , TACT 1
S3510 CST1A024ZT SW , TACT 1
S3511 CST1A024ZT SW , TACT 1
S3512 CST1A024ZT SW , TACT 1
S3513 CST1A024ZT SW , TACT 1
S3514 CST1A024ZT SW , TACT 1
S3515 CST1A024ZT SW , TACT 1
CMC1A332 SHIELD , DIGITAL AVR755 1
CMC1A335 SHIELD , IR AVR755 1
CMH1A285 HOLDER , VFD AVR755 1
DP3501 CFL18BT19GINK F.I.P , AVR755(18-BT-19GINK) 18BT019GINK 1
L3501 HLQ02C4R7KT INDUCTOR 4.7UH AL02TB4R7K 4.7uH 1.7ohm +10% 1
L3504 HLQ02C470KT COIL , AXAIL AL02TB470K 47uH 5.8ohm +10% 1
JA3501 CJJ4S046Z JACK , RCA (3P, 303, YL WH RD, AU) RCA-303G-06 1
JA3502 CJJ9M006Z JACK , DIN (1P, S-VHS, 434A, AU PL) DIN-434AG 1
JA3503 HJJ2E021Z JACK , HEADPHONE HTJ-035-13B 1
JA3504 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1
JA3505 CJJ4M061Z JACK , RCA (1P, 107BAG, OR, AU PL) RCA-107BAG-02 ORANGE 1
JA3506 HJJ2E017Z JACK HTJ064-05BG 1
JA3507 CJJ9X007Z JACK , USB (GOLD) 317AE04XXA100X 1
N3501 CWB1B011400GN 11P WIRE ASS'Y(400MM, 2.0MM) UL1007#26(TA) 400mm 2mm 11P RED 1
N3502 CWB1C004080GN 4P WIRE ASS'Y(80MM, 2.0MM) UL1007#26(TA) 80mm 2mm 4P RED 1
N3503 CJP21GB116ZY WAFER GF120-21S-LS 1.25mm 21P 1
N3504 CWB1B007200GN 7P WIRE ASS'Y(200MM, 2.0MM) UL1007#26(TA) 200mm 2mm 7P RED 1
N3505 CWB1C005150GN 5P WIRE ASS'Y(150MM, 2.0MM) UL1007#26(TA) 150mm 2mm 5P RED 1
N3506 CWB1B003080GN 3P WIRE ASS'Y(80MM, 2.0MM) UL1007#26(TA) 80mm 2mm 3P RED 1
N3507 CWBAVR755N3507 5P WIRE ASS'Y (550MM,2.0MM) UL2547/1533#26(TA) 550mm 2mm 5P RED 1
N3509 CWBAVR755N3509 5P WIRE ASS'Y(700MM, 2.0MM) UL1007/1533#24(TA) 700mm 2mm 5P RED 1
N3510 CWBAVR755N3510 4P WIRE ASS'Y(250MM, 2.0MM) UL2547/1007#26(TA) 250mm 2mm 4P RED 1
N3511 CWBAVR755N3511 5P WIRE ASS'Y (350MM,2.0MM) UL2725+ABE USB2.0 350mm 2mm 5P RED 1
N3516 CWB1B003080GN 3P WIRE ASS'Y(80MM, 2.0MM) UL1007#26(TA) 80mm 2mm 3P RED 1
N3521 CJP10GB99ZY WAFER 35237-1010 2.0mm 10P WHT 1
N3522 CJP19GB99ZM WAFER(19P, AN 2MM) 35237-1910 2.0mm 19P WHT 1
N3523 CJP19GB99ZM WAFER(19P, AN 2MM) 35237-1910 2.0mm 19P WHT 1
N3524 CJP16GB99ZM WAFER(16P, AN 2MM) 35237-1610 2.0mm 16P WHT 1
N3525 CJP10GB99ZY WAFER 35237-1010 2.0mm 10P WHT 1
N3526 CJP19GB99ZM WAFER(19P, AN 2MM) 35237-1910 2.0mm 19P WHT 1
N3527 CJP07GB99ZY HOUSING 35237-0710 2.0mm 7P WHT 1
N3528 CJP10GB99ZY WAFER 35237-1010 2.0mm 10P WHT 1
P3508 CJP06GA47ZW WAFER,2mm GIL-S-6P-S2T2-EF 6P 1
P3512 CJP04GB48ZW WAFER(4P, AN 2MM) GIL-S-04P-S2L2-EF 4P 1
P3513 CJP05GA47ZW WAFER,2mm GIL-S-5P-S2T2-EF 5P 1
P3515 CJP03GB48ZW WAFER (3PIN, AN, 2MM, JWT) GIL-S-03P-S2L2-EF 3P 1
P3517 CJP03GB48ZW WAFER (3PIN, AN, 2MM, JWT) GIL-S-03P-S2L2-EF 3P 1
P3531 CJP10GA98ZY WAFER 35336-1010 2.0mm 10P WHT 1
P3532 CJP19GA98ZM WAFER(19P, ST 2MM) 35336-1910 2.0mm 19P WHT 1
P3533 CJP19GA98ZM WAFER(19P, ST 2MM) 35336-1910 2.0mm 19P WHT 1
P3534 CJP16GA98ZM WAFER(16P, ST 2MM) 35336-1610 2.0mm 16P WHT 1
P3535 CJP10GA98ZY WAFER 35336-1010 2.0mm 10P WHT 1
P3536 CJP19GA98ZM WAFER(19P, ST 2MM) 35336-1910 2.0mm 19P WHT 1
AVR 7550HD harman/kardon
42
