Ref. Designator Part Number Description Qty
MAIN HEAT SINK ASS'Y CUP12037Y
IC131 HVIKIA7812API I.C , REGULATOR +12V KIA78XXAPI 1
IC132 HVIKIA278R12PI REGULATOR(12V OUTPUT LOW DROP) KIA278R12PI 1
IC133 CVIKIA278R15PI I.C , REGULATOR(15V OUTPUT LOW DROP) KIA278R15PI-U/P 1
IC134 CVIKIA7915PI I.C , REGULATOR(15V, TO-220AB) KIA7915PI 1
IC135 CVIKIA7824API I.C , VOL-REGULATOR(24V TO-220IS) KIA7824API 1
IC136 HVIKIA7812API I.C , REGULATOR +12V KIA78XXAPI 1
IC137 CVIKIA7824API I.C , VOL-REGULATOR(24V TO-220IS) KIA7824API 1
D140 CVD2W04MMFRS2 DIODE , BRIDGE(RC-2 KINK TYPE) 2W04MMFRS2 , DELTA 1
D141 CVD2W04MMFRS2 DIODE , BRIDGE(RC-2 KINK TYPE) 2W04MMFRS2 , DELTA 1
IC138 HVINJM2068DD I.C , DUAL OP AMP NJM2068DD 1
IC233 CVILM19CIZ2.4V I.C , TEMP SENSOR LM19CIZ2.4V , NATIONAL(T I) 1
Q231 HVTKTC3114A TRANSISTOR , BIAS NPN KTC3114A 1
Q232 HVTKTC3114A TRANSISTOR , BIAS NPN KTC3114A 1
Q233 HVTKTC3114A TRANSISTOR , BIAS NPN KTC3114A 1
Q234 HVTKTC3114A TRANSISTOR , BIAS NPN KTC3114A 1
Q323 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1
Q324 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1
Q327 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1
Q328 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1
Q429 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1
Q430 HVTKTC3423Y TRANSISTOR , PRE DRIVE NPN KTC3423Y 1
Q431 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1
Q432 HVTKTA1360Y TRANSISTOR , PRE DRIVE PNP KTA1360Y 1
Resistors
R101 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
R102 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
R105 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
R106 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
R109 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
R110 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
R113 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
R114 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
R121 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R140 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
R141 CRD20TJ273T RES , CARBON 27K OHM 1/5W J 1
R142 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1
R143 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1
R150 CRD20TJ473T RES , CARBON 47K OHM 1/5W J 1
R151 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
R152 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J 1
R194 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
R195 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
R196 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
R197 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
R207 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R209 CRD20TJ273T RES , CARBON 27K OHM 1/5W J 1
R211 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
R214 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R215 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1
R216 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R217 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R218 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R219 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R220 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R223 CRD20TJ513T RES , CARBON 51K ohm 1/4W 5% 1
R224 CRD20TJ274T RES , CARBON 270K ohm 1/4W 5% 1
R225 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1
R231 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R234 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R235 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1
R236 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1
R237 CRD20TJ821T RES , CARBON 820 OHM 1/5W J 1
R238 CRD20TF2801T RES , CARBON 2K8 ohm 1/4W 5% 1
R239 CRD20TJ821T RES , CARBON 820 OHM 1/5W J 1
R240 CRD20TF2801T RES , CARBON 2K8 ohm 1/4W 5% 1
R241 CRD20TJ821T RES , CARBON 820 OHM 1/5W J 1
R242 CRD20TF2801T RES , CARBON 2K8 ohm 1/4W 5% 1
R243 CRD20TJ821T RES , CARBON 820 OHM 1/5W J 1
R244 CRD20TF2801T RES , CARBON 2K8 ohm 1/4W 5% 1
