Harman Kardon AVR1550 Service Manual

pos Part number qty description
1 55178050 1 AC PUN COVER TOP
2 55155740 1 DISPLAY HNA-10MM22
3 55088400 1 CONN-PHJAC 6.35 ST HORZ EST-J6313
4 55124350 1 AC PUN BRACKET HEADPHONE
5 55178000 1 SWIPUSH POWER SWITCH 5.0A 250.0V 100MI0OHM 1T 2P
6 55498980 1 AC MLD BUTTON INDICATOR STAND-BY AVR1550 --
7 55177810 1 AC DEC BUTTON POWER HIPS
8 55498880 1 AC DEC BUTTON STANDBY AVR1550
9 55510880 1 AC CPL PLATE BADGE HARMAN/KARDON GOLD
10 55498750 1 AC DEC CABINET PANEL FRONT AVR1550
11 55177800 1 AC DEC CRYSTAL FILTER DISPLAY
12 55498790 1 AC DEC CRYSTAL DISPLAY AVR1550
13 55177740 1 AC DEC KNOB MAIN HIPS 94H
14 55230130 1 AC DEC BUTTON 7 KEY
15 55498770 1 AC DEC BUTTON 8 KEY AVR1550 --
16 55113740 1 CON PHONO SCKT RCA-307 3 PINS
17 55113960 1 CON DIN SCKT SOCKET CONNECTOR SVHS EST-S408J
18 55145270 20 SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM
19 55178960 1 AC SPRING PLATE SPRING GND C5212 0.2T AVR520
20 55134900 1 SWIROT EC16B24204A5 5V 500U0A 10T 3P
21 55244320 1 AC MLD HOLDER FL-GUIDE HIPS 94HB
22 55155930 1 IC-REMOTE RPM6938-RSIP-A3 RECEIVER 38KHZ
23 55178250 1 AC CPL CABINET CHASSIS FRONT SECC 1.0T
24 55192650 1 AC CPL CABINET CHASSIS MAIN
25 55124310 1 AC PUN BRACKET TRANS
26 55630390 1 TF-LAM POWER-TRANSFORMER 230V
27 5522774A 1 EPR TUNER MODULE KST-M1114MW1-60A
28 55126350 1 AC MLD BUTTON SUPPORT
29 55149520 3 CON DIN SCKT MIX SOCKET RCA-118JP1S
30 55178170 2 AC PUN BRACKET FRAME-GUIDE SECC T1.0 --
31 55499080 1 AC CPL REAR PANEL AVR1550
32 55125180 1 AC MLD CLAMP AC CORD
33 20720110 1 WIRE-MCRDM 0.82MM2 2000MM BK
34 55261080 10 AC KNOB CORK SH08M790B0 BK PL
35 20634190 3,5 FELT BK 30.0MM X 25.0MM 0.8MM 0MM 0 0
36 55311150 1 AC HEATSINK DIODE
37 55212250 1 CABLE-FIX CLAMP WIRE UL DENNISON 0 0
38 55262240 1 CONN-SPE TERMINAL SPKR 6P -- FE 4.5MM 6 GN 0 0
39 55298430 1 AC HEATSINK REG TR 3P
40 55130170 1 AC HEATSINK REG TR 2P
41 55191390 1 CONN-SPE TERMINAL SPKR 4P SH0410376P FE 19MM
42 55262230 1 CON PHONO SCKT RCA 2P
43 55176330 2 CON PHONO SCKT RCA 4P JW4104RS GND
44 55088230 1 CON PHONO SCKT RCA-606P 6 PINS
45 55191370 1 CON PHONO SCKT RCA 1P JACK JE010003XN
46 55246370 2 CON PHONO SCKT RCA 1P W/GND JE010003LN OG
AVR1550 EXPLODED VIEW PART LIST 2002.10.05
