When you wish to use the 6-Channel/8-Channel
Direct Input
j in conjunction with a video source,
you must first select the video source by pressing one
of the
Input Selectors e, then press this button to
choose the device connected to the
6-Channel/8-
Channel Direct Input
j as the audio source.
Mute: Press this button to momentarily silence
the AVR 330 or TV set being controlled, depending on
which device has been selected. When the AVR 330
remote is being programmed to operate another device,
this button is pressed with the
Input Selector Button
e to begin the programming process. (See page
35 for more information on programming the remote.)
EzSet Sensor Microphone: The sensor micro-
phone for the EzSet microphone is behind these slots.
When using the remote to calibrate speaker output
levels using EzSet, be sure that you do not hold the
remote in a way that covers these slots. (See page 23
for more information on using EzSet.)
