Ref. Designator Part Number Description
FRONT PCB ASS'Y
D728 HVD1SS133MT DIODE
1SS133T-77
D729 HVD1SS133MT DIODE
1SS133T-77
D730 HVD1SS133MT DIODE
1SS133T-77
D761 HVD1SS133MT DIODE
1SS133T-77
D774 HVD1SS133MT DIODE
1SS133T-77
D775 HVD1SS133MT DIODE
1SS133T-77
D776 KVD1N4003ST DIODE
1N4003
D777 HVD1SS133MT DIODE
1SS133T-77
D778 KVD1N4003ST DIODE
1N4003
D779 HVD1SS133MT DIODE
1SS133T-77
D783 HVD1SS133MT DIODE
1SS133T-77
D784 HVD1SS133MT DIODE
1SS133T-77
D785 HVD1SS133MT DIODE
1SS133T-77
D786 HVDMTZJ5.6BT DIODE , ZENER
5.6V ZENER
D787 HVDMTZJ5.6BT DIODE , ZENER
5.6V ZENER
D788 HVDMTZJ5.6BT DIODE , ZENER
5.6V ZENER
D789 HVDMTZJ5.6BT DIODE , ZENER
5.6V ZENER
IC87 HVIRE5VL28CATZ IC , RESET
2.8V I.C , RESET
Q701 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q702 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q703 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q704 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q705 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q706 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q722 HVTKRA107MT TRANSISTOR NPN
KRA107M
Q723 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q724 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q725 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q726 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q727 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q728 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q729 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q731 KVTKSA1175YT TRANSISTOR NPN
KSA1175Y
Q732 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q733 KVTKSC2785YT TRANSISTOR NPN
KSC2785Y
Q734 HVTKTC2874BT TRANSISTOR , NPN, MUTE
KTC2874B
Q735 HVTKTC2874BT TRANSISTOR , NPN, MUTE
KTC2874B
Q736 HVTKTC2874BT TRANSISTOR , NPN, MUTE
KTC2874B
Q737 HVTKTC2874BT TRANSISTOR , NPN, MUTE
KTC2874B
Q738 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q739 HVTKTA1271YT TRANSISTOR PNP
KTA1271Y
Q740 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q741 HVTKRC107MT TRANSISTOR NPN
KRC107M
Q743 HVTKRA107MT TRANSISTOR NPN
KRA107M
D702 CVD52CSBBCEAB2 BLUE L.E.D
D703 CVD52CSBBCEAB2 BLUE L.E.D
D704 CVD52CSBBCEAB2 BLUE L.E.D
D706 CVD52CSBBCEAB2 BLUE L.E.D
D707 CVD52CSBBCEAB2 BLUE L.E.D
D723 CVD50BOBBWGA L.E.D , 2 COLOR
IC72 BVIMB90F482APFG IC , FLASH U-COM
FUJITSU
IC73 HRVRPM6938H4 SENSOR , REMOTE
RPM6938-H4
IC74 HVIS3F84BB I.C , FLASH U-COM
S3F84BB
IC75 HVI74ACT04MTR I.C , HEX
IC76 HVITC74HCU04AFN IC , INVERTER
TC74HCU04AFN
IC80 HVIHCF4053M013T I.C
S.T
IC81 HVINJM2068MDTE1 I.C , OP AMP
NJM2068MD-TE1
IC82 HVINJM2068MDTE1 I.C , OP AMP
NJM2068MD-TE1
IC83 HVI74ACT04MTR I.C , HEX
IC84 HVI74ACT04MTR I.C , HEX
IC85 HVIRH5VT18C I.C , RESET
1.8V I.C , RESET
34
AVR330 harman/kardon
