Harman Kardon AVR330 User Manual

Ref. Designator Part Number Description
MAIN PCB ASS'Y
Q823 HVTKTC3200GRT TRANSISTOR NPN KTC3200GR
Q824 HVTKTC3198YT TRANSISTOR NPN KTC3198Y
Q825 HVTKTC3198YT TRANSISTOR NPN KTC3198Y
Q826 HVTKTC2874BT TRANSISTOR, NPN, MUTE KTC2874B
Q827 HVTKTC2874BT TRANSISTOR, NPN, MUTE KTC2874B
Q901 KVTKSC2785YT TRANSISTOR NPN KSC2785Y
Q902 HVTKRA107MT TRANSISTOR NPN KRA107M
Q903 HVTKRA107MT TRANSISTOR NPN KRA107M
Q904 HVTKRC107MT TRANSISTOR NPN KRC107M
Q911 HVTKTA1271YT TRANSISTOR PNP KTA1271Y
Q912 HVTKTA1271YT TRANSISTOR PNP KTA1271Y
Q913 HVTKTA1271YT TRANSISTOR PNP KTA1271Y
Q914 HVTKTA1271YT TRANSISTOR PNP KTA1271Y
Q915 KVTKSC2785YT TRANSISTOR NPN KSC2785Y
Q916 KVTKSC2785YT TRANSISTOR NPN KSC2785Y
Q917 KVTKSC2785YT TRANSISTOR NPN KSC2785Y
Q918 KVTKSC2785YT TRANSISTOR NPN KSC2785Y
Q938 HVTKRA107MT TRANSISTOR NPN KRA107M
Q939 HVTKRA107MT TRANSISTOR NPN KRA107M
Q942 KVTKSC2785YT TRANSISTOR NPN KSC2785Y
Q943 KVTKSC2785YT TRANSISTOR NPN KSC2785Y
Q951 HVTKRC107MT TRANSISTOR NPN KRC107M
Q952 HVTKRA107MT TRANSISTOR NPN KRA107M
Q960 HVTKRC107MT TRANSISTOR NPN KRC107M
Q961 HVTKTA1024YT TRANSISTOR PNP KTA1024Y
Q969 HVTKTC2874BT TRANSISTOR, NPN, MUTE KTC2874B
Q970 HVTKTC2874BT TRANSISTOR, NPN, MUTE KTC2874B
Q971 HVTKTC2874BT TRANSISTOR, NPN, MUTE KTC2874B
Q972 HVTKTC2874BT TRANSISTOR, NPN, MUTE KTC2874B
Q973 HVTKTC2874BT TRANSISTOR, NPN, MUTE KTC2874B
Q991 HVTKRC107MT TRANSISTOR NPN KRC107M
Q992 HVTKRA107MT TRANSISTOR NPN KRA107M
Q993 HVTKRA107MT TRANSISTOR NPN KRA107M
Q994 HVTKRC107MT TRANSISTOR NPN KRC107M
Q995 HVTKRA107MT TRANSISTOR NPN KRA107M
Q652 BVT2SB1647-OKM TRANSISTOR, NPN, POWER 2SB1647
Q653 BVT2SB1647-OKM TRANSISTOR, NPN, POWER 2SB1647
Q654 BVT2SB1647-OKM TRANSISTOR, NPN, POWER 2SB1647
Q655 BVT2SB1647-OKM TRANSISTOR, NPN, POWER 2SB1647
Q657 BVT2SD2560-OKM TRANSISTOR, NPN, POWER 2SD2560
Q658 BVT2SD2560-OKM TRANSISTOR, NPN, POWER 2SD2560
Q659 BVT2SD2560-OKM TRANSISTOR, NPN, POWER 2SD2560
Q660 BVT2SD2560-OKM TRANSISTOR, NPN, POWER 2SD2560
Q661 BVT2SB1647-OKM TRANSISTOR, NPN, POWER 2SB1647
Q670 BVT2SD2560-OKM TRANSISTOR, NPN, POWER 2SD2560
Q803 BVT2SD2560-OKM TRANSISTOR, NPN, POWER 2SD2560
Q804 BVT2SB1647-OKM TRANSISTOR, NPN, POWER 2SB1647
Q805 BVT2SD2560-OKM TRANSISTOR, NPN, POWER 2SD2560
Q807 BVT2SB1647-OKM TRANSISTOR, NPN, POWER 2SB1647
IC94 HVIMC7805C I.C, REGULATOR KA7805-ABTU
IC95 BVIKP1010B IC, PHOTO COUPLER
IC96 BVIKP1010B IC, PHOTO COUPLER
Q858 HVT2SA1360O TRANSISTOR PNP 2SA1360
Q871 HVT2SA1360O TRANSISTOR PNP 2SA1360
Q872 HVT2SA1360O TRANSISTOR PNP 2SA1360
Q874 HVT2SA1360O TRANSISTOR PNP 2SA1360
Q875 HVT2SA1360O TRANSISTOR PNP 2SA1360
Q876 HVT2SA1360O TRANSISTOR PNP 2SA1360
Q877 HVT2SA1360O TRANSISTOR PNP 2SA1360
Q881 HVT2SC3423O TRANSISTOR PNP 2SA1360
Q882 HVT2SC3423O TRANSISTOR PNP 2SA1360
