Ref. Designator Part Number Description
MAIN PCB ASS'Y
R956 CRD20TJ394T RES , CARBON 390K OHM 1/5W J
R957 CRD20TJ153T RES , CARBON 15K OHM 1/5W J
R958 CRD20TJ563T RES , CARBON 56K OHM 1/5W J
R959 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R960 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R961 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R962 CRD20TJ273T RES , CARBON 27K OHM 1/5W J
R963 CRD20TJ105T RES , CARBON 1M OHM 1/5W J
R964 CRD20TJ105T RES , CARBON 1M OHM 1/5W J
R966 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R969 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R970 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R971 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R972 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R973 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R974 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R975 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R976 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R977 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R978 CRD20TJ331T RES , CARBON 330 OHM 1/5W J
R979 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R980 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R981 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R982 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R983 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R986 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R987 CRD20TJ561T RES , CARBON 560 OHM 1/5W J
R988 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R989 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R991 CRD20TJ822T RES , CARBON 8.2K OHM 1/5W J
R992 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J
R998 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R656 CRF5EKR27HX2 RES , CEMENT 0.27OHM(*2) ,5W
R657 CRF5EKR27HX2 RES , CEMENT 0.27OHM(*2) ,5W
R658 CRF5EKR27HX2 RES , CEMENT 0.27OHM(*2) ,5W
R659 CRF5EKR27HX2 RES , CEMENT 0.27OHM(*2) ,5W
R660 CRF5EKR27HX2 RES , CEMENT 0.27OHM(*2) ,5W
R810 CRF5EKR27HX2 RES , CEMENT 0.27OHM(*2) ,5W
R811 CRF5EKR27HX2 RES , CEMENT 0.27OHM(*2) ,5W
R904 BRDERC12UGK335T RES , CARBON JP 3.3M OHM 1/2W
R905 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W
R923 CRD25TJ220T RES , CARBON 22 OHM 1/4W
R990 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W
R993 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W
R994 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W
R995 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W
R996 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W
R997 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W
R999 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W
Miscellaneous
CMD1A387 BRACKET , PCB
CMYAVR330CC HEAT SINK ASS'Y
CHD1A012Z SCREW , SPECIAL AVR125CC
CHD1A036FZ SCREW , SPECIAL AVR330/AVR4600
CMD1A398 BRACKET , PCB AG-D9320
CMD1A417 BRACKET , PCB AG-D8900
CMD1A488 BRACKET , FAN
CMY1A205 HEAT SINK
CTB3+8J SCREW
AVR330 harman/kardon
