D. Combustion Fan Chamber
Monthly Cleaning- continued:
The combustion inlet cover is located behind the ash pan
that must be removed to properly clean the combustion fan
blade.Figure2.4.
• Removecombustioninletcoverbypullinguponcover.
This allows access to the combustion fan blade and
exhaustpath.Figure2.4.
• Removeanyyashordebristhathascollectedaround
combustion fan blade with the provided paint brush.
• Cleanexhaustpassage.
NOTE: The ESP Sensor is located just inside the exhaust
passage. Be sure not to damage the ESP Sensor while
cleaning the exhaust passage.
• Oncecleanedreplacecombustioninletcoverandashpan.
Figure 2.4
Exhaust Passage
Combustion Fan Blade
Combustion Inlet Cover
E. Glass Maintenance
The glass used in your stove is manufactured to exact standards
to withstand the high heat of the re, but like all glass, it must be
treated with common sense and care. Never abuse the glass by
slamming the door shut or striking the glass with a heavy object.
If the glass is broken or damaged, do not operate the stove until
it has been replaced.
Glass - Cleaning
It will be necessary to clean accumulated ash from the glass
surface;allowingthisashtoremainontheglassforlongperiods
canresultin“etching”duetotheacidityoftheash.Nevercleanthe
glasswhileitishot,anddo not use abrasive substances. Wash
thesurfacewithcoolwater,andrinsethoroughly.Youmaywishto
useanon-abrasivecleanerspecicallydesignedforuseonstove
glass.Inanycase,drythoroughlybeforerelightingyourstove.
Glass - Replacement
Ifthestove’sglassiscrackedorbroken,youmustreplaceitbefore
operatingyourstove.Removepiecescarefully.Replaceglassonly
withHarman
®
replacementglass;do not use substitutes.
Glass Gasket
Replace glass only with high temperature mirrored ceramic glass.
Inspect door gasket during cleaning
and inspection
Glass - Replacement (Cont.)
Carefullyremovedamagedglass,gasketmaterial,andhold
downclips(setaside).
Installtheselfadhesive1/4”gasketmaterialaroundthefront
faceoftheglass.Settheglasspanelandgasketgentlyonto
thedoor.Installtheholddownclipsandtightenwithbolts.
Besuretokeepringandde-ashingdoorsclosedandinsure
all seals are maintained and are in good condition
F. Firebox
Yearly Cleaning:
Removeyashandcarbonbuildupfromthesmoothsurfaces
of the heat exchanger as well as other surfaces inside the
rebox.Figure2.7.
Figure 2.7
Scrape these areas free of yash or
carbon buildup
