Service Parts
Absolute 43
Beginning Manufacturing Date: March 2015
Ending Manufacturing Date: Active
IMPORTANT:THISISDATEDINFORMATION.Partsmustbeorderedfromadealer
or distributor. Hearth and Home Technologies does not sell directly to consum-
ers.Providemodelnumberandserialnumberwhenrequestingservicepartsfromyour
dealer or distributor.
Stocked at
Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
12 BurnPotScraper Pkgof10 2-00-777692-10
13 Ashlip
Black 3-00-777644P
MajolicaBrown 1-00-777644-14
14 AshDoor,Complete 1-10-777570A
Gasket3/84Strand 30Feet 1-00-00888 Y
15 AshDoorHandleAssembly 1Set 1-00-777149 Y
Rollers&Hardware 1Set 1-00-77723 Y
16 AshPan 1-10-777604A Y
17 BurnPotAssembly
17.1 BurnPotWeldment 1-10-777801A Y
Gasket 3-44-724114 Y
17.2 SwingPlate&FlameGuide 1Set 1-00-777818 Y
17.3 Igniterw/Bracket 1-00-777200 Y
17.4 IgniterBracketFront Pkgof5 1-00-777815
17.5 BurnPotGrate 1-00-777800 Y
17.6 BurnPotCleanOutw/Hardware 1-00-777824 Y
5/16-18WingScrew Pkgof25 3-30-8012-25 Y
18 LegLevelingKit 1Set 1-00-12302
19
Legw/Hardware
Black
1-00-249100 Y
MajolicaBrown
1-00-249100-14 Y
20 RightSideCast
Black 4-00-777646P
MajolicaBrown 1-00-777646-14
21 CombustionBlower 1-00-02275 Y
FanBlade 1-10-574500A Y
PoundInStud6-32X11/4 Pkgof30 1-00-53463220
22 Gasket,BurnPot/Tailpipe Pkgof5 1-00-07381 Y
23 PelletTailpipe,Cast 3-00-247237 Y
24 PowerCord 3-20-51578 Y
25 Gasket,BurnPot/Tailpipe Pkgof5 1-00-07381 Y
Additional service parts on following page.
#17 Burn Pot Assembly
17.1
17.2
17.4
17.3
17.5
17.6
