Harman Accentra Pellet Insert User Manual

25
3-90-00674R28_12/13
WheninstallingtheAccentraInsertintoafactorybuiltwood
burning replace, the Manufactured Fireplace Installation
Kit#1-00-674205mustbeused.Inaddition,severalthings
needtobetakenintoconsideration.
The size of the replace opening. Will the unit t into the
opening? Many of these units have metal smoke shields
insidethetopthatcanberemovedtogainheight.Oftenthe
sideandrearrefractorycanberemovedtogaindepthand
width.Insomecircumstances,thefrontlowerliporgrillwork
mayalsoberemoved.Besureandfollowtheguidelinesin
thekitinstructions.Becauseofthespecialtracksystem,itis
alsopermittedtoremovetheoorrefractoryand/orinsulation
inthebottomofthemanufacturedreplace,rightdownto
theoutersheetmetal,whichmustbeleftinplaceforoor
protectionundertheinsertmountingframe.Floorprotection
guidelines,aslistedonpage14mustalsobefollowed.
OPTIONAL HOPPER CONFIGURATIONS FOR SMALLER FIREPLACE
OPENINGS:
TheHarmanAccentraInsertcanbefactorybuiltwithshorterhopper
congurations.
Thestandardrequiresa24"opening.Part#1-90-00674
Option1:Requiresa22"openingheight.Part#1-90-00675
Option2:Requiresa20"openingheight.Part#1-90-00676
Keepinmindthehoppercapacitieswilldecreasewiththeoptionalheights.
Venting
Note: If the Harman Accentra Insert is installed into a factory built wood burning replace, this label (Harman
part # 3-90-00675) MUST be attached to the altered replace. This label is included in the Manufactured replace
installation kit.
Fig.54
Installing the Accentra Insert into an existing
factory built wood burning replace
Fig.53
