Harman AMX MU Series User Manual

pg. 12
MU-1000
The MU-1000 (AMX-CCC000) has 4 GB of on-board DDR3 RAM, a commercial grade 8GB eMMC non-volatile memory
storage chip and an ICSLan control network. It is PoE powered and has a small form factor for easy installation. It
features the MUSE scripting engine which supports a variety of standard programming languages to create the business
logic for the control system. A complete list of device specifications is listed below.
MU-1000 Specifications
Dimensions
5.14" x 5.04" x 1.18" (130.5 x 128 x 30 mm)
Power Requirements
PoE 36-57V @ 350mA Max
Power Consumption
15.4W Maximum - PoE 802.3af Class 0
Mean Time Between Failure (MTBF)
100000 hours
Memory
4 GB DDR3 RAM
8 GB eMMC
Weight
1.26 lbs (572g)
Enclosure
Powder Coated Steel – Gray Pantone 10393C
Certifications
• ICES 003
• CE EN 55032
• AUS/NZ CISPR 32
• CE EN 55035
• CE EN 62368-1
• IEC 62368-1
• UL 62368-1
• VCCI CISPR 32
• RoHS / WEEE compliant
Front Panel Components
Status LED
RGB LED – see Status LED Detailed Description
ID button
ID pushbutton used during boot to revert to factory configuration or
factory firmware
USB-C Program Port
Connection to PC for virtual terminal for MU configuration
LAN Link/Activity LED
Lit when connected to a network. Blinks upon network activity
ICSLan Link/Activity LED
Lit when connected to a network. Blinks upon network activity
Rear Panel Components
LAN Port
RJ-45 10/100 BASE-T for Ethernet communication and PoE
Auto MDI/MDI-X
DHCP Client
