Harman AMX MU Series User Manual

pg. 14
MU-1300
The MU-1300 (AMX-CCC013) has 4 GB of on-board DDR3 RAM, a commercial grade 8GB eMMC non-volatile memory
storage chip and an ICSLan control network. It is a small form factor for easy installation. It features the MUSE scripting
engine which provides a variety of standard programming languages to create the business logic for the control system.
A complete list of device specifications is listed below.
MU-1300 Specifications
Dimensions
5.8" x 5.16" x 1.66" (147.32mm x 131mm x 42.16 mm)
Power Requirements
• DC input voltage (typical): 12 VDC
• DC current draw: 2.17A Max
• DC range, voltage: 9-18 VDC
Power Consumption
26 Watts Max
Mean Time Between Failure (MTBF)
100000 hours
Memory
4 GB DDR3 RAM
8 GB eMMC
Weight
1.58 lb (718g)
Enclosure
Powder Coated Steel – Gray Pantone 10393C
Certifications
• ICES 003
• CE EN 55032
• AUS/NZ CISPR 32
• CE EN 55035
• CE EN 62368-1
• IEC 62368-1
• UL 62368-1
• VCCI CISPR 32
• RoHS / WEEE compliant
Front Panel Components
Status LED
RGB LED – see Status LED Detailed Description
ID button
ID pushbutton used during boot to revert to factory configuration or
factory firmware
USB-C Program Port
Connection to PC for virtual terminal for MU configuration
USB-A Host Port
Type-A USB host port
• USB Mass Storage – for external logging
•
FLIRC – IR Receiver for IR hand control input
LAN Link/Activity LED
Lit when connected to a network. Blinks upon network activity
