Harman AMX MU Series User Manual

pg. 19
…MU-3300 Specifications continued
Rear Panel Components
Power
3.5mm Phoenix 2-pin connector with retention screws for 12vdc input
LAN Port
RJ-45 10/100 BASE-T for Ethernet communication
Auto MDI/MDI-X
DHCP Client
ICSLan Port
RJ-45 10/100 BASE-T for Ethernet communication
Auto MDI/MDI-X
DHCP server
Provides isolated control network
RS-232/422/485 Port 1 & 5
3.5mm Phoenix 10-pin connector
• 12VDC @0.5A
• RX- Balanced line input for RS-422/485
• RX+ Balanced line input for RS-422/485
• TX- Balanced line output for RS-422/485
• TX+ Balanced line output for RS-422/485
• RTS Ready to Send for Hardware Handshaking
• CTS Clear to Send for Hardware Handshaking
• TXD Unbalanced line output for RS-232
• RXD Unbalanced line input for RS-232
•
GND – Signal ground for RS-232
RS-232 Ports 2-4 & 6-8
3.5mm Phoenix 5 pin connector
• RTS Ready to Send for Hardware Handshaking
• CTS Clear to Send for Hardware Handshaking
• TXD Unbalanced line output for RS-232
• RXD Unbalanced line input for RS-232
•
GND – Signal ground for RS-232
Relays 1-8
3.5mm Phoenix 8 pin connector
4 pairs – Contact Closure output for Normally Open contact
IR 1-8
3.5mm Phoenix 8 pin connector
4 pairs – IR/Serial output + ground
I/O 1-8
3.5mm Phoenix 6 pin connector
• 12VDC @0.5A
• 4x I/0 pins configurable as Analog In, Digital In, or Digital Out
•
Ground
USB Host Port
2x Type-A USB host port
• USB Mass Storage – for external logging
•
FLIRC – IR Receiver for IR hand control input
General Specifications:
Operating Environment
• Operating Temperature: 32° F (0° C) to 122° F (50° C)
• Storage Temperature: 14° F (-10° C) to 140° F (60° C)
• Operating Humidity: 5% to 85% RH
•
Heat Dissipation (On): 10.2 BTU/hr
Included Accessories
• 1x 2-pin 3.5 mm mini-Phoenix PWR connector
• 2x 6-pin 3.5 mm mini-Phoenix I/O connectors
• 2x 8-pin 3.5 mm mini-Phoenix Relay connectors
• 2x 10-pin 3.5mm mini-Phoenix RS232/422/485 connectors
• 6x 5-pin 3.5mm mini-Phoenix RS232 connectors
• 2x CC-NIRC, IR Emitters (FG10-000-11)
• 2x removable rack ears
