Harman Martin MAC Aura XIP - Ludicrous Mode

34 MAC Aura XIP User Manual
Ludicrous Mode
MAC Aura XIP firmware version 1.0.0.
See “Pixel mapping” on page 9 for details of Aura filament numbering.
Channels 1 - 57: as in Extended Mode
Aura Filament color (Filament Color Control of 12 x Aura LEDs, Global Aura RGB channels are added to this
using HTP)
58
0 - 255
Filament 1 Red
0 - 100%
Fade 0
59
0 - 255
Filament 1 Green
0 - 100%
Fade 0
60
0 - 255
Filament 1 Blue
0 - 100%
Fade 0
61
0 - 255
Filament 2 Red
0 - 100%
Fade 0
62
0 - 255
Filament 2 Green
0 - 100%
Fade 0
63
0 - 255
Filament 2 Blue
0 - 100%
Fade 0
64
0 - 255
Filament 3 Red
0 - 100%
Fade 0
65
0 - 255
Filament 3 Green
0 - 100%
Fade 0
66
0 - 255
Filament 3 Blue
0 - 100%
Fade 0
67
0 - 255
Filament 4 Red
0 - 100%
Fade 0
68
0 - 255
Filament 4 Green
0 - 100%
Fade 0
69
0 - 255
Filament 4 Blue
0 - 100%
Fade 0
70
0 - 255
Filament 5 Red
0 - 100%
Fade 0
71
0 - 255
Filament 5 Green
0 - 100%
Fade 0
72
0 - 255
Filament 5 Blue
0 - 100%
Fade 0
73
0 - 255
Filament 6 Red
0 - 100%
Fade 0
74
0 - 255
Filament 6 Green
0 - 100%
Fade 0
75
0 - 255
Filament 6 Blue
0 - 100%
Fade 0
76
0 - 255
Filament 7 Red
0 - 100%
Fade 0
77
0 - 255
Filament 7 Green
0 - 100%
Fade 0
78
0 - 255
Filament 7 Blue
0 - 100%
Fade 0
79
0 - 255
Filament 8 Red
0 - 100%
Fade 0
80
0 - 255
Filament 8 Green
0 - 100%
Fade 0
81
0 - 255
Filament 8 Blue
0 - 100%
Fade 0
82
0 - 255
Filament 9 Red
0 - 100%
Fade 0
83
0 - 255
Filament 9 Green
0 - 100%
Fade 0
84
0 - 255
Filament 9 Blue
0 - 100%
Fade 0
85
0 - 255
Filament 10 Red
0 - 100%
Fade 0
