Harman P43 Installation Manual

Harman® • P-Series Installation Manual_R3 • 2014 -___ • 09/1418 3-90-436168i
E. Locating Your Appliance & Chimney
Locationoftheapplianceandchimneywillaffectperformance.
• Installthroughthewarmairspaceenclosedbythebuilding
envelope.This helps to produce more draft, especially
duringlightinganddie-downofthere.
• Penetratethehighestpartoftheroof.Thisminimizesthe
effectsofwindloading.
• Locate termination cap away from trees, adjacent
structures,unevenrooflinesandotherobstructions.
• Minimizetheuseofchimneyoffsets.
• Considertheappliancelocationrelativetooorandceiling
andatticjoists.
G. Negative Pressure
F. Draft
Draftisthepressuredifferenceneededtoventappliances
successfully.Whenanapplianceisdraftingsuccessfully,all
combustionbyproductsareexitingthehomethroughthe
chimney.
Considerationsforsuccessfuldraftinclude:
• Preventingnegativepressure
• Locationofapplianceandchimney
Tomeasurethedraftornegativepressureonyourappliance
use a magnahelic or a digital pressure gauge capable of
reading0-1inchesofwatercolumn(W.C.).
The appliance should be running on high for at least 15
minutesforthetest.
Withthestoverunningonhighyoushouldhaveanegative
pressureequaltoorgreaterthanthenumbergiveninthe
chartbelow.Ifyouhavealowerreadingthanyoundonthe
chart,yourappliancedoesnothaveadequatedrafttoburn
thefuelproperly.
Minimum Vacuum Requirements: .35 - .55
• DONOTCONNECTTHISUNITTOACHIMNEYFLUE
SERVICINGANOTHERAPPLIANCE.
• DO NOT CONNECT TOANYAIR DISTRIBUTION
DUCTORSYSTEM.
Mayallowuegasestoenterthehouse
Priortoinstallingtheuepipe,connectadraftmeter.(The
draftmetermusthaveaminimumrangeof0-.5”)Recordthe
rstreading.Connectuepipetostoveandbesurealldoors
andwindowsinthehomeareclosed.Recordtheseconddraft
reading_______.If thesecondreadingismore than .05”
lowerthantherstreading,checkforpossiblerestrictions
ortheneedforoutsideair.Formoreinformationonthedraft
testprocedure,refertoPage21
CAUTION
!
Negativepressureresultsfromtheimbalanceofairavailable
fortheappliancetooperateproperly.Itcanbestrongestin
lowerlevelsofthehouse.
Causesinclude:
• Exhaustfans(kitchen,bath,etc.)
• Rangehoods
• Combustionairrequirementsforfurnaces,waterheaters
andothercombustionappliances
• Clothesdryers
• Locationofreturn-airventstofurnaceorairconditioning
• ImbalancesoftheHVACairhandlingsystem
• Upperlevelairleakssuchas:
 - Recessedlighting
 - Attichatch
 - Ductleaks
Tominimizetheeffectsofnegativeairpressure:
• Installtheoutsideairkitwiththeintakefacingprevailing
windsduringtheheatingseason
• Ensureadequateoutdoorairforallcombustionappliances
andexhaustequipment
• Ensurefurnaceandairconditioningreturnventsarenot
locatedintheimmediatevicinityoftheappliance
• Avoidinstallingthe applianceneardoors,walkwaysor
smallisolatedspaces
• Recessedlightingshouldbea“sealedcan”design
• Attichatchesweatherstrippedorsealed
• Atticmountedductworkandairhandlerjointsandseams
tapedorsealed
NOTICE: Hearth & Home Technologies assumes no
responsibilityfortheimproperperformanceofthechimney
systemcausedby:
• Inadequatedraftduetoenvironmentalconditions
• Downdrafts
• Tightsealingconstructionofthestructure
• Mechanicalexhaustingdevices
Risk of Asphyxiation! Negative pressure can cause
spillageofcombustionfumesandsoot.
WARNING
!

Harman P43 Specifications

General

Fuel Type	Pellet
Ignition	Automatic
Thermostat	Yes
Heating Area	Up to 2, 200 sq ft
Blower	Yes
Warranty	Limited
