Feeder Chamber
This chamber may get a buildup of nes from the feeder
mechanismmovement.Thisarea should bechecked and
cleanedatleastonceayear.
To remove the feeder cover:
• Loosenthe5/16"wingnut.Figure5.8.
• Liftupandslidethecoveroffofthethreadedstud.
• InspectandcleantheinnerchamberifnecessaryFigure
5.9.
• Reinstallthecovermakingcertainitisseatedproperlyon
thefeederbodyandtightenastightlyasyoucanbyhand.
NOTE: Views are shown with the rear motor covers
removed.
Pellet Metering
Slide Plate
Possible pellet nes
buildup area.
Figure 5.9
5/16" Wing NutFeeder clean out cover
Figure 5.8
G. Pellet Feeder Chamber
