D21m System

6 D21M MODULES

6.1 Available Cards

Name

I/O

Format

# of Console

Input Channels

# of Console

Output Channels

Connector Type Width (Slots) Order No.

Analog I/O Cards

*Mic/Line Input (incl. Dir. Outs)

Mic/Line 4 (4 Dir. Outs) D25 f single A949.0427

*Analog Insert

Line 4 4 D25 f single A949.0428

*HD Mic/Line Input with Input

*Transformers (incl. Dir. Outs)

Mic/Line 4 (4 Dir. Outs) D25 f single A949.0447

Analog Line In

Line 8 – D25 f single A949.0421

Analog Line Out

Line – 8 D25 f single A949.0420

Digital I/O Cards

AES I/O M2 (no SRCs)

AES/EBU 8 stereo (16 mono) 8 stereo (16 mono) 2 × D25 f

double **

A949.0454

AES I/O M2 (Input SRCs)

AES/EBU 8 stereo (16 mono) 8 stereo (16 mono) 2 × D25 f

double **

A949.0455

AES I/O M2 (In/Out SRCs)

AES/EBU 8 stereo (16 mono) 8 stereo (16 mono)

2 × D25 f;

ext. sync XLR

double **

A949.0456

MADI I/O ***/****

MADI

64 at 48 kHz (32 with red.,

64 without red. at 96 kHz)

64 at 48 kHz (32 with red.,

64 without red. at 96 kHz)

SC (optical)

2 × RJ45

double **

A949.0430

A949.0431

A949.0433

ADAT I/O

ADAT 16 at 48 kHz (8 at 96 kHz) 16 at 48 kHz (8 at 96 kHz) TOSLINK (optical) single

A949.0425

A949.0429

TDIF I/O

TDIF 16 at 48 kHz (8 at 96 kHz) 16 at 48 kHz (8 at 96 kHz) 2 × D25 f

double **

A949.0426

3G/HD/SD SDI Input

3G/SD/HD 8/16 – 2 × BNC single A949.0452

HD/SD SDI I/O

HD/SD 8 8 4 × BNC single A949.0442

3G/HD/SD SDI I/O

3G/HD/SD 16 16 4 × BNC single A949.0451

Dolby

E/Digital Decoder

AES/EBU

2 stereo (4 mono)

4 stereo (8 mono)

D15 f single

A949.0443

A949.0444

CobraNet

I/O

CobraNet 32 32 2 × RJ45 single A949.0445

Aviom A-Net

Output

A-Net – 16 RJ45 single A949.0446

EtherSound

I/O ***

EtherSound 64 64 3 × RJ45 double ** –

BCD DTMF Dec./Glits Gen.

Internal 16 8 – single –

BCD Blits/Glits Gen.

Internal – 8 – single –

BCD Minimixer

Internal 32 32 – single –

Non-Audio I/O Cards

GPIO w. Open-Collector Outp.

GPIO 16 16 2 × D25 f

double **

A949.0435

GPIO w. Relay Outputs

GPIO 16 16 2 × D37 f

double **

A949.0436

HD Cards

HD S

HD Link max. 96 max. 96 4 × RJ45 single A949.0412

HD RS422

HD Link +

RS422

max. 96 max. 96 4 × RJ45, D9 f

double **

A949.0415

MADI HD

MADI

64 at 48 kHz (32 with red.,

64 without red. at 96 kHz)

64 at 48 kHz (32 with red.,

64 without red. at 96 kHz)

SC (optical)

RJ45

double **

A949.0411.3x

A949.0413.3x

A949.0414.3x

Serial / Merger Cards

Serial

RS422 – – D9 f single A949.0437

Serial Merger

RS422 – – 2 × D9 f single A949.0438

Serial RJ45

RS422 – – RJ45 single A949.0439

Dual Merger RJ45

RS422 – – 4 × RJ45 single A949.0440

* The Analog Insert card belongs to the Mic/Line Input card A949.0427 at its left. The insert send signal is always present and may be used as an additional

direct output. The insert return is activated from the console.

Please note that the Analog Insert card does not communicate with the HD card, and it is not supported by the HD Mic/Line Input card A949.0447.

** Double-width cards must be inserted into odd slot numbers (e.g. slots 1, 3, 5…).

*** The number of channels transmitted to and from a card may be defined in steps of 8 channels by using DIP switches on the card.

**** Regardless of the number of channels defined with the DIP switches, a switch on the front panel switches the MADI protocol between the standard 56-chan-

nel format and the extended 64-channel format. Therefore this switch may have to be set to ‘56 channel’ protocol in order to operate correctly with third-

party MADI devices. In this case the number of channels set internally should not exceed 56.

Supply / Miscellaneous

Primary Power Supply Unit

A949.0404

Fan Unit

A949.0597

LED/PSII PCB

A949.0402

XLR Break-Out Boxes

div.

Extender Card

A949.0408
