Harman TL300 User Manual

Save These Instructions Harman® • TL300 Owner's Manual_R25 • 2007 -___ • 08/15 3-90-06901
Service Parts
TL300
Beginning Manufacturing Date: Aug. 2007
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
1 Rear Air Jacket 1-10-06928P
Bolt, 1/4-20 x 5/8 Grade 8.2 Zinc Flange SAE Pkg of 50 3-30-2001-50
Y
2 Combustion Package Cover 2-00-06922L
3 Combustion Package w/Gaskets 3-40-06999
Y
Gasket Set, Complete 3-44-06999
Y
Package Cover 2-00-06996B
Y
4 Gasket, Brick Air Pkg of 4 3-44-2500202-4
Y
5 Outside Air Plate 2-00-06943P
5/16-18 x 1 1/4" Grade 5 Zinc Plated Hex Cap Screw Pkg of 50 3-30-1129-50
Y
6 Top Air Grill Assembly 1-10-06946P
7 Top Load Door Assembly 1-10-06921A Y
Dowel Pin, .250 x .375 Pkg of 15 3-30-2019-15
Top Load Door Gasket Plate 1-10-40020
Y
Gasket. Top Load Door 1-00-10050
Y
Hinge Spacer Qty 2 req 2-00-40021L
Lid Hinge Set, Bottom 1-00-40022
Y
Nut, Zinc Plated Acron Pkg of 50 3-30-8014-50
Y
8 Left Side Shield 2-00-06926P
Y
9
Andrion and Andiron Extension Set w/Hardware 2-00-05222-1
Y
Screw, 5/16-18 x 3/4" Grade 5 Zinc Plated Hex Cap Pkg of 100 3-30-1125-100
Y
Washer, 5/16" Zinc Plated USS Flat Pkg of 100 3-30-0204-100
Y
10 Front Load Door Assembly 1-10-06920A
Ball Spring Bracket 2-00-06714
Cast Door, Painted 4-00-06920P
Door Latch 1-00-249119 Y
Gasket, Glass 15 Ft 1-00-2312
Y
Gasket. Load Door 30 Ft 1-00-00888
Y
Glass Clips w/Hardware Pkg of 4 2-00-05202-4
Y
Glass, Load Door w/Gasket 1-00-06932
Y
Mounting Screw for Handle, 1/4"-20 x 2 1/2" Pkg of 25 3-30-6007-25
Y
Screw, 10-24 x 3/8", Button Head Cap for Glass clips Pkg of 100 3-30-3011-100
Y
Wooden Handle 1-00-00247
Y
11 Ash Door Assembly 1-10-06915A
Ash Door Latch 3-00-249149
Gasket, Ash door 5 Ft 1-00-10000
Y
Wooden Knob, Ash Door Pkg of 3 3-40-08746-3
12 Bolt on Ash Door Hinge 2-00-06952B
Y
Additional service part numbers appear on following page.
