Harmopool Hydrolyse EC20 - Troubleshooting Small Steering Box

27
Problem solution for the small steering box
PROBLEM
CAUSE
SOLUTION
Screen does not light up
No voltage present
Verify voltage
Acid pump does not dose
Switch under the dosing pump
is set to "O"
Set switch to "1"
Settings of pH control are wrong
: pH+ while pH- is dosed (or vice
versa)
Verify settings
There is a level detector
connected that gives a wrong
contact
Disconnect level detector
There is a flow siwtch
connected and this indicates
that there is no flow
Verify flow and flow switch (go
to setting flow switch : no)
Acid pump keeps dosing
Setpoint not yet reached
No action required
Wrong parameter set : pH+
while dosing pH- (or vice versa)
Correct parameter.
Relay on printed circuit board
sticks
Contact supplier.
Acid pump only doses
occasionally
Acid pump stands on
proportional dosing
No action required
Acid pump does not pump.
There is a flow siwtch
connected and this indicates
that there is no flow
Verify flow and flow switch (go
to setting flow switch : no)
There are level detectors
connected that give a wrong
contact
Disconnect level detectors
Acid pump does not suck up
liquid
Barrel is empty or suction foot
hangs above liquid level
Replace acid or chlorine
container; Lower suction foot.
Suction foot is clogged
Replace suction foot
ZWMX2205-Z
Peristaltic hose is leaking
Replace peristaltic hose
ZWMX2231-Z
Injection nozzle is clogged
Replace injection nozzle
ZWMX2220-Z
Liquid (acid ) in dosing
compartment of acid pump
Santoprene dosing tube leakage
Verify that dosing nipple is
clogged, and replace dosing
tube.
Dosing tube in pH forms a
bladder
Supply of acid or chlorine in
injection nipple curdled by dirt /
calcification
Immediately stop acid dosing
and clean/replace nipple. Use
liquid chlorine with
anticalcification
