DA-DHR/DH/DSR/DS/HR/H6802+ Installation and Operation Manual 19
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 3
Operation
Overview
This chapter describes how to operate DA-DHR/DH/DSR/DS/HR/
H6802+ modules using local controls only. See the following
documents for information on how to operate this product remotely:
• + Pilot Lite™ User Manual for serial control interface
• CCS™ Navigator™, Pilot™, CoPilot™, or RCP-CCS-1U Remote
Control Panel Installation and Operation Manual for Ethernet
control interface
The following topics are discussed in this chapter:
• “Changing Parameter Settings” on page 26
• “LEDs and Alarms” on page 27
• “Operating Notes” on page 20
• “Setting Locally Controlled Parameters” on page 23
• “Setting Remotely Controlled Parameters” on page 24
• “Understanding Jumper Controls” on page 20
• “Understanding Parameter Types” on page 22
