DA-DHR/DH/DSR/DS/HR/H6802+ Installation and Operation Manual 27
Chapter 3: Operation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
LEDs and Alarms
Module Status Indicator LED
Figure 3-2. Module Status Indicator LED
A module status LED reports the state of the module. See Figure 3-1 on
page 20 for the location of this LED, and Table 3-4 for a definition of
the LED colors.
Table 3-4. Module Status Indicator LED Descriptions
LED Color Sequence Meaning
Off There is no power to the module; the module is
not operational
Green There is power to the module; the module is
operating properly
Amber There is an alarm condition
