Table 3-3. DA-DHR6802+, DA-DSR6802+, DA-HR6802+ Remotely Controlled Parameters
Name Range Description
Backup mode
• 0 = Disable
•1 = Enable
Loss of signal (input 1) switching enable,
automatically switch both output MUXs to select
input 2 when input 1 has lost its input signal
Output configuration
• 0=1×4
• 1=1×8 ch. 1
• 2=1×8 ch. 2
Allows you to select if the card is in dual 1×4 or 1×8,
input 1 routed to all outputs; or 1×8 with input 2
routed to all outputs
Locked data rate [RO]
• 0=Unknown
•1=270
•2=HD
• 3=HD 3.0*
•4=Bypass
Displays the locked input rate; if the input cannot be
locked, “Bypass” is displayed
Signal present [RO]
•0=No
•1=Yes
Indicates if the Input is present or not
Reclocking mode
• 0=Auto
•1=270
•2=HD
• 3=HD 3.0*
•4=Bypass
Allows you to select the reclock rate for the input
Loss of input alarm
• 0=Disable
•1=Enable
Enables or disables the Loss of Input alarm
Loss of lock alarm
• 0=Disable
•1=Enable
Enables or disables the Loss of Lock alarm
Slew rate*
•0=HD
•1=SD
•2=Auto
Allows you to specify slew rate as either HD (1.485
Gb/s or 3.0 Gb/s) or SD
* DA-DHR6802+ only
