2 DA-DHR/DH/DSR/DS/HR/H6802+ Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 1: Introduction
Product Description
The DA-DHR/DH/DSR/DS/HR/H6802+ series of distribution
amplifiers are designed to distribute serial digital video signals
according to SMPTE 257C, 292M, 424M, DVB, and other related
standards. They feature high reliability, excellent video performance,
and low cost.
The individual modules are available in the following configurations:
• DA-DHR6802+: dual channel 3-Gb/s / HD / SD distribution
amplifiers with reclocking (see page 2 for a list of its main features)
• DA-DH6802+: dual channel 3-Gb/s / HD / SD distribution
amplifiers (see page 3 for a list of its main features)
• DA-DSR6802+: dual channel SD distribution amplifiers with
reclocking (see page 3 for a list of its main features)
• DA-DS6802+: dual channel SD distribution amplifiers (see page 3
for a list of its main features)
• DA-HR6802+: single channel 3-Gb/s / HD / SD distribution
amplifiers with reclocking (see page 4 for a list of its main features)
• DA-H6802+: single channel 3-Gb/s / HD / SD distribution
amplifiers (see page 4 for a list of its main features)
You can set up, control, and monitor these distribution amplifier
modules either locally (via a card-edge jumper) or remotely (via
RS-232 ports or optional ICE6800+ Ethernet connection).
Main Features
DA-DHR6802+
• Configurable as a single channel of one input and eight outputs
(1×8), or two independent channels of one input and 4 outputs
• Enable automatic switching input between input 1 and input 2 in the
l×8 configuration when a loss of the input signal is detected
• Input signal presence detect and report
• Automatic input cable equalization
• Maximum equalized cable length adjustable (for 270Mb/s and
remotely only)
• Reclocking Mode selectable as automatic or manual
• Re-lockable for 270Mb/s, 1.5Gb/s and 3.0Gb/s SMPTE signal
