18 DA-DHR/DH/DSR/DS/HR/H6802+ Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 2: Installation
Installing 6800+ Modules
Required Frames and Back Module Connector Types
These modules have double-width back connectors that can be installed
in an FR6802+ series frame. See the FR6802+ Frame Installation and
Operation Manual for details on installing back connectors in an
FR6802+ frame.
These modules cannot be installed in 6800 / 7000 series frames.
Installing Modules
These modules require no specialized installation procedures. See the
FR6802+ Frame Installation and Operation Manual for information
about installing and operating an FR6802+ frame and its components.
Removing Modules
These modules require no specialized removal procedures. See the
FR6802+ Frame Installation and Operation Manual for information
about removing components in an FR6802+ frame.
Making Connections
Once you have installed the module, you can connect it to the
appropriate input and outputs.
