Chapter 1: Introduction
• Enable automatic switching input between input 1 and input 2 in the
1×8 configuration when a loss of the input signal is detected.
• Input signal presence detect and report
• Automatic input cable equalization
• Maximum equalized cable length adjustable (remotely only)
• Direct fanout the input signal (5Mb/s to 540Mb/s) without
reclocking
• Card edge control by jumpers with LED display
• Remote control via RS-232 or Ethernet
DA-HR6802+
• One input, eight outputs
• Input signal presence detect and report
• Automatic input cable equalization
• Maximum equalized cable length adjustable (for 270 Mb/s and
remotely only)
• Reclocking Mode selectable as automatic or manual
• Re-lockable for 270Mb/s, 1.5 Gb/s and 3.0 Gb/s SMPTE signal
• Re-lockable for DVB-ASI signal
• Reclock status and rate report by LEDs
• Reclocking Bypass mode is selectable as automatic or enforced
• Card edge control by jumpers with LED display
• Remote control via RS-232 or Ethernet
DA-H6802+
• One input, eight outputs
• Input signal presence detect and report
• Automatic input cable equalization
• Maximum equalized cable length adjustable (for 270 Mb/s and
remotely only)
• Direct fanout the input signal (5 Mb/s to 3 Gb/s) without reclocking
• Card edge control by jumpers with LED display
• Remote control via RS-232 or Ethernet
Typical Broadcast and Production Applications
DA-DHR/DH/DSR/DS/HR/H6802+ distribution amplifiers can be
used in broadcast, cable, production, educational, and auditorium
applications where a low cost method of distributing dual channel
signals is required.
