Harrison 32Classic MS - Output; MIX Section

Tutorial
Front Panel Controls
Mix Output Section
Note: Use the supplied ‘Sum Link’ cable to access the MIX OUTPUT section of the 32Classic MS during single unit use.
1 - Fader Output Level
Controls the 32Classic MS post fader output level. Also adjusts the level to the MIX bus when routed.
2 - FADER 0dB
Locks the 32Classic MS post fader output level at 0dB bypassing the FADER potentiometer.
3 - PAN
Activates the pan potentiometer allowing the signal to be Panned left and right when routed to the MIX bus.
12 32Classic MS
