HART HLPM01 User Manual

5 – English
FEATURES
PRODUCT SPECIFICATIONS
Motor......................................................................................................................................................................40 Volt DC
DeckSize....................................................................................................................................................................... 20in.
HeightAdjustments........................................................................................................................................1-1/2in.to4in.
WheelSize..............................................................................................................................................8in.front,10in.rear
KNOW YOUR LAWN MOWER
See Figure 1.
The safe use of this product requires an understanding of the
information on the product and in this operator’s manual as
wellasaknowledgeoftheprojectyouareattempting.Before
use of this product, familiarize yourself with all operating
featuresandsafetyrules.
BATTERY COVER
Thebatterycoverprotectsthebatteryportfrommoisture
anddebris.
BATTERY STORAGE COMPARTMENT
Thebatterystoragecompartmentoffersaconvenientplace
forstoringyourbatteryortostoreanextrabatterypack.
START KEY
The start key must be inserted before the mower can be
started.
GRASS CATCHER
The grass catcher collects grass clippings and prevents
themfrombeingdischargedacrossyourlawnasyoumow.
HEIGHT ADJUSTMENT LEVER
The height adjustment lever provides cutting height
adjustments.
LED HEADLIGHTS
LED headlights are located on the front of the unit to illumi-
nateyourpathinlowlightconditions.Thelightswilloperate
continuouslywheneverthemotorisrunning.
NOTE:Ifthethestartbuttonispressedorthebailissqueezed
andreleased,theheadlightswillilluminateforsixtyseconds.
MULCHING PLUG
Yourmowerisequippedwithamulchingplugthatcovers
the rear discharge opening, which allows the mower blade
tocutandrecutforfinerclippings.
START BUTTON AND BAIL
The start button and bail are located on the upper handle of
themower.Depressthestartbuttonthenengagethebailto
startthemotor.Releasethebailtostopthemotor.
TILT SENSOR
Thetiltsensorpreventstheunitfromstartingifitisina
verticalpositionortiltedatananglegreaterthan45º.
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
A
Amperes
Current
Hz
Hertz
Frequency (cycles per second)
W
Watt
Power
hrs
Hours
Time
