HART HLPM02 User Manual

6 – English
ASSEMBLY
WARNING:
Topreventaccidentalstarting,donotmakeanyad-
justments or installations with the start key or battery
packinserted.Accidentalstartingofthemowerduring
assemblycouldresultinseriouspersonalinjury.
WARNING:
Neveroperatethemowerwithoutthepropersafetyde-
vicesinplaceandworking.Neveroperatethemower
with damaged safety devices. Operating the mower
with missing or damaged parts can result in serious
personalinjury.
UNFOLDING AND ADJUSTING THE HANDLE
ASSEMBLY
See Figures 2 - 3.
NOTICE:
Do not allow the starter cable to become pinched or
trappedwhenraisingthehandle.
Therearetwohandleheightpositionsforusercomfort.
 Raisethehandleassembly.Avoidpinchingortrapping
anycables.
NOTE: There are two stop positions for a higher and
loweradjustmentofthehandle.Thisallowsforamore
comfortableoperatingposition.
To raise the lower handle:
 Pull the handle adjustment knobs out and rotate
90degrees.
 Raise the lower handle. Avoid pinching or trapping any
cables.
 Rotatetheknob90degreesagaintosecurehandleinplace.
To raise the upper handle:
 Openthehandlelockclips.
 Fullyextendtheupperhandle.
 Close the handle lock clips to secure the upper handle
inplace.Avoidpinchingortrappinganycables.
ASSEMBLING THE GRASS CATCHER
See Figures 4 - 5.
 Placethegrasscatcherframeonaflatsurfacewiththe
handlefacingdown.
 Orientthegrasscatcherbagsothevinylfloorisfacing
up,thenslidetheframeintothebag.Wheninstalling,
allow the frame handle to remain outside the bag and
makesurethebagseamsarelocatedattheframeedges.
 Pulltheclipovertheframerailtosecureinplace.
 Liftthebag’svinylfloortothetopoftheframerailand
secureinplace.
UNPACKING
Thisproductrequiresassembly.
 Carefullyremovetheproductandanyaccessoriesfrom
thebox.MakesurethatallitemslistedinthePacking
Listareincluded.
WARNING:
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it.Partsonthislistarenotassembledtotheproductby
themanufacturerandrequirecustomerinstallation.Use
ofaproductthatmayhavebeenimproperlyassembled
couldresultinseriouspersonalinjury.
 Inspect the product carefully to make sure no breakage
ordamageoccurredduringshipping.
 Donotdiscardthepackingmaterialuntilyouhavecare-
fullyinspectedandsatisfactorilyoperatedtheproduct.
 If any parts are damaged or missing, please call
1-800-776-5191forassistance.
PACKING LIST
Lawn Mower
Start Key
Grass Catcher Bag and Frame
MulchingPlug
Operator’sManual
WARNING:
If any parts are damaged or missing, do not operate this
productuntilthepartsarereplaced.Useofthisproduct
with damaged or missing parts could result in serious
personalinjury.
WARNING:
Do not attempt to modify this product or create acces-
soriesnotrecommendedforusewiththisproduct.Any
such alteration or modification is misuse and could result
in a hazardous condition leading to possible serious
personalinjury.
WARNING:
Do not insert start key or battery pack until assembly is
completeandyouarereadytomow.Failuretocomply
could result in accidental starting and possible serious
personalinjury.

HART HLPM02 Specifications

General

Brand	HART
Model	HLPM02
Category	Lawn Mower
Language	English
