3. Safety Distances
Theindicatedsafetydistancesapplytoammable
materialsormaterialswithammablepartswitha
thermalresistanceofR≤6m²K/W.
Forparticularlytemperature-sensitivematerialslike
glass,largerdistancesmaybenecessary.
Withinaradiusof100cm infront ofand45cm
aroundthestove,ammable,combustible,orheat-
sensitivematerials(e.g.furniture,woodorplastic
panelling,curtains,etc.)arenotallowedtobelo-
catedintheheatradiatingareaofthereboxwin-
dow(g.1).
Outsidetheradiationareaofthere boxwindow,
asafetydistanceof15cmtoammablematerials
is to comply sideways and behind the stove
(g. 1). Above the stove, the safety distance of
50cmtoammablematerialshastobecomplied
with(g.2).
No ammable or temperature-sensitive materials
maybepresent within a radius of 20 cm around
theuepipeconnection(wallorroomceiling).
WARNING!
Flammable ooring materials (e.g., wood,
laminate, carpeting,) must be protected
with a oorplate made of non-combustible
material (e.g., tiles, safety glass, slate, or
sheet steel).
The size of the oorplate must be larger
than the base of the stove by at least
Dimensionsincm
50 cm in front and at least 23 cm at the
sides of the stove (g. 2).
Depiction of safe distances without rotary
function. Should a base plate be neces-
sary, the range of rotation of the chimney
stove must be adapted (g. 3).
g. 1
100
45
15
100
44
15
15
g. 2
g. 3
23
23
50
oor-
plate
50
50
