HASE LIMA - Technical Data

44
Dimensionsincm
13. Technical Data
TheLima C.16 / Sila,certiedincompliancewith DIN-EN 13240 and Art. 15 a
B-VG (Austria),canonlybeoperatedwhenthereboxisclosed.Conformswith
theDIBt(DeutschenInstitutfürBautechnik/GermanInstituteforBuildingTechnol-
ogy)approvalcriteriafordirectventreplacesforsolidfuels.Multiple connections
to the chimney are possible, see point 4. “Connection of Multiple Devices in Direct
Vent Operation”. DIBt approval number:Z-43.12-396(FC61x)
The following data applies to the chimney characteristics in accordance with
EN 13384-1 / 2
Combustion Values* Wood
NominalThermalOutput 6 kW
Roomheatingoutput 6,4 kW
Exhaustgastemperature 256 ˚C
Efciency 81 %
Particulate 16 mg/Nm³
OGC 59 mg/Nm³
NO
X
104 mg/Nm³
COcontentat13%O
2
1000 mg/Nm³
WasteGasMassFlowRate 5,6 g/s
WasteGasOutletTemp. 308 ˚C
Min.SupplyPressureatNominalThermalOutput**
12
Pa
Min.requiredcombustionairvolume 25 m³/h
Dependingontheinsulationofthebuilding,thenominalthermaloutputof6 kW
indicatedon20 - 80 m² (subjecttochange).
Dimensions: Height Width Depth
Stove 126cm 47cm 47cm
Firebox 40 cm 31 cm 28 cm
***Forseparateairsupplyinlow-energyhousesandinsufcientcombustionairsupplyintheroom
 wherethestoveisinstalled.
Front view Lima C.16 / Sila:
Side view Lima C.16 / Sila:
Top view Lima C.16 / Sila:
1
min. 30
¹Verticaluepipelength min.30cm
Fluepipediameter 15cm
PipediameterofHaseventilationsystem*** 10cm
30
126Stoveheight
47
118 Heightfortopinstallation
23,5
10 Heightfortheinst.ofHasairsystem
13,5 Inst.ofHaseair
 systembelow
* Testbenchperformanceandvalues
** TheadditionalsupplypressurerequiredforthecombustionairconnectionwiththeHaseAirSystem: 
 behind=3Pa
WeightLimaC.16(ceramic/soapstone) 195/220kg
WeightSila(steelceramic/soapstone) 140/180/200kg
Weight1xheatretainingblock 82kg
