HASE LIMA - Technical Data

45
Front view Sila Plus:
Side view Sila Plus:
Dimensionsincm
Technical Data
The Sila Plus, certiedin compliance with DIN-EN 13240 and Art. 15 a B-VG
(Austria),canonly be operatedwhentherebox is closed.Conforms with the
DIBt(DeutschenInstitutfürBautechnik/GermanInstituteforBuildingTechnology)
approvalcriteriafordirectventreplacesforsolidfuels.Multiple connections to the
chimney are possible, see point 4. “Connection of Multiple Devices in Direct Vent
Operation”. DIBt approval number:Z-43.12-396(FC61x)
The following data applies to the chimney characteristics in accordance with
EN 13384-1 / 2
Combustion Values* Wood
NominalThermalOutput 6 kW
Roomheatingoutput 6,4 kW
Exhaustgastemperature 256 ˚C
Efciency 81 %
Particulate 16 mg/Nm³
OGC 59 mg/Nm³
NO
X
104 mg/Nm³
COcontentat13%O
2
1000 mg/Nm³
WasteGasMassFlowRate 5,6 g/s
WasteGasOutletTemp. 308 ˚C
Min.SupplyPressureatNominalThermalOutput**
12
Pa
Min.requiredcombustionairvolume 25 m³/h
Dependingontheinsulationofthebuilding,thenominalthermaloutputof6 kW
indicatedon20 - 80 m² (subjecttochange).
Dimensions: Height Width Depth
Stove 141cm 47cm 47cm
Firebox 40 cm 31 cm 28 cm
Fluepipediameter 15cm
PipediameterofHaseventilationsystem*** 10cm
Stoveheight
141
118 Heightfortopinstallation
47
1
min. 30
Top view Sila Plus:
10 Heightfortheinst.ofHasairsystem
13,5 Inst.ofHaseair
 systembelow
23,5
Weightincl.heatretainingblock141kg 291kg
¹Verticaluepipelength min. 30 cm
***Forseparateairsupplyinlow-energyhousesandinsufcientcombustionairsupplyintheroom
 wherethestoveisinstalled.
* Testbenchperformanceandvalues
** TheadditionalsupplypressurerequiredforthecombustionairconnectionwiththeHaseAirSystem: 
 behind=3Pa
