HASE Sendai - Safety Distances

41
3. Safety Distances
Theindicatedsafetydistancesapplytoammable
materialsormaterialswithammablepartswitha
thermalresistanceofR≤6m²k/W.
For particularly temperature-sensitive materials like
glass, larger distances may be necessary.
Within a radius of 60 cm in front of and 40 cm
aroundthestove,ammable,combustible,orheat-
sensitive materials (e.g. furniture, wood or plastic
panelling, curtains, etc.) are not allowed to be lo-
catedintheheatradiatingareaofthereboxwin-
dow(g.1).
Behind the stove, outside the area of radiation, the
following safety distance to ammable materials
hastobecompliedwith(g.1):
A
Sendai 135 = 16 cm
B
Sendai 175 = 10 cm
No ammable or temperature-sensitive materials
may be present within a radius of 20 cm around
the ue pipe connection (wall or room ceiling).
Above the stove, the following safety distances
to ammable materials have to be complied with
(g.2).
WARNING!
Flammable ooring materials (e.g., wood,
laminate, carpeting,) must be protected
with a oorplate made of non-combustible
material (e.g., tiles, safety glass, slate, or
sheet steel).
The size of the oorplate must be larger
than the base of the stove by at least
50 cm in front and at least 27 cm at the
sides of the stove (g. 3).
Dimensions in cm
g. 1
60
40
40
43º
16 10
A
B
43º
43º
60
40
40
43º
43º
43º
30
30
g. 2
50
70
30
g. 3
27
27
50
oor-
plate
