Hatco DL-400 User Manual

Form No. DHLM-1207
3
SPECIFICATIONS
ELECTRICAL RATING CHART
The electrical information in the shaded area pertains to Export Models only.
Figure 1. Lamp Dimensions
Lamp Shade Diameter Height
Style (A) (B)
DL-400 6-1/8" 8-1/2"
(156 mm) (216 mm)
DL-500 6-1/8" 8-1/2"
(156 mm) (216 mm)
DL-700 6-1/2" 8-1/2"
(165 mm) (216 mm)
DL-725 9-1/2" 8-1/2"
(241 mm) (216 mm)
DL-750 11" 8-1/2"
(279 mm) (216 mm)
DL-760 12-1/2" 8-1/2"
(318 mm) (216 mm)
DL-775 10-1/2" 8-1/2"
(267 mm) (216 mm)
DL-800 11" 8-1/2"
(279 mm) (216 mm)
DIMENSIONS – SHADE
A
A
A
A
B
B
B
B
Model DL-400 Model DL-500
Model DL-725
Model DL-750
Model DL-760 Model DL-775 Model DL-800
Model DL-700
A
A
A A
B
B
B
B
NOTE: The height dimension of the shade increases by 2" (51 mm) when utilizing the “L” lower switch location.
Model Voltage Watts Amps
DL Series 120 250 2.1
240 250 1.1
DLH Series 120 375 3.2
