HDWCEM1-0822
6
Model
Width
(A)
Depth
(B)*
Height
(C)
Built-In
Width(D)
Built-In
Height(E)
HDW-1B 743 mm
568 mm
276 mm
715 mm
248 mm
HDW-2B 743 mm
568 mm
534 mm
715 mm
506 mm
HDW-3B 743 mm
568 mm
791 mm
715 mm
763 mm
HDW-1BN 523 mm
680 mm
276 mm
494 mm
248 mm
HDW-2BN 523 mm
680 mm
534 mm
494 mm
506 mm
HDW-3BN 523 mm
680 mm
791 mm
494 mm
763 mm
Model
Width
(A)
Depth
(B)
Height
(C)
Footprint
Width(D)
Footprint
Depth(E)
HDW-1 749 mm
(29-1/2
575 mm
(22-5/8
279 mm
(11
629 mm
(24-3/4
484 mm
(19-1/16
HDW-2 749 mm
(29-1/2
575 mm
(22-5/8
)
537 mm
(21-1/8
629 mm
(24-3/4
484 mm
(19-1/16
HDW-3 749 mm
(29-1/2
575 mm
(22-5/8
794 mm
(31-1/4
629 mm
(24-3/4
484 mm
(19-1/16
HDW-4 749 mm
(29-1/2
575 mm
(22-5/8
1051 mm
(41-3/8
629 mm
(24-3/4
484 mm
(19-1/16
HDW-1N 530 mm
(20-7/8
686 mm
(27
279 mm
(11
408 mm
(16-1/8
594 mm
(23-7/16
HDW-2N 530 mm
(20-7/8
686 mm
(27
537 mm
(21-1/8
408 mm
(16-1/8
594 mm
(23-7/16
HDW-3N 530 mm
(20-7/8
686 mm
(27
794 mm
(31-1/4
408 mm
(16-1/8
594 mm
(23-7/16
SPECIFICATIONS
Dimensions — HDW-xB and HDW-xBN Models
Dimensions — HDW-x and HDW-xN Models
NOTE:Add102mm(4″)toHeight(C)forunitswithstandard102mm(4″)plasticlegs(add152mm[6″]forunitswith152mm[6″]
legs). For additional legs and casters information, refer to the OPTIONS AND ACCESSORIES section of this manual.
Model
Width
(A)
Depth
(B)*
Height
(C)
Built-In
Width(D)
Built-In
Height(E)
HDW-1BR 740 mm
418 mm
273 mm
715 mm
248 mm
HDW-2BR 740 mm
418 mm
546 mm
715 mm
521 mm
HDW-3BR 740 mm
418 mm
819 mm
715 mm
794 mm
Dimensions — HDW-xBR Models
* Add35mm(1-3/8″)toDepth(B)fortheunitdepthdimensionincludingtheconduitconnector.
