1B20 | 1B27 | 1B30 | 1B40 | 1B50

www.HATZ-DIESEL.com

Hat z Diesel

CREATI NG POWER SOLUTI ONS.

OPERATOR’ S MANUAL

Diesel engine

0000 433 802 10 - 01.2013 - 3

Printed in Germany

ENG

Table of Contents

Other manuals for Hatz Diesel 1B20

Original Instruction Book63 pages

Instruction Book34 pages

Questions and Answers

S
Sandra Oneal MDAug 15, 2025
How to troubleshoot starting issues with my Hatz Diesel Engine?
- K
  Kimberly PattonAug 15, 2025
  If your Hatz Diesel Engine won't start or hesitates but turns easily, make sure the speed control lever is in the "START" position. Also, check if there is fuel at the injection pump by adding fuel and systematically checking the entire fuel supply. Insufficient compression may be the issue, so check and adjust the tappet clearance if needed. If the temperature is below the start limit, activate the pre glow unit (if equipped). For cylinder/piston ring wear or a non-functional injection nozzle, contact the HATZ service station.
U
uweaverAug 18, 2025
What to do if my Hatz Diesel 1B20 Engine hesitates or won't start?
- A
  Amy GreenAug 18, 2025
  If your Hatz Diesel Engine hesitates or doesn't start but turns easily, here are a few things to check: * **Speed control lever position:** Ensure the speed control lever is in the "START" operating position and the stop pin is not in the STOP position. * **Fuel supply:** Add fuel and systematically check the entire fuel supply system to ensure fuel is reaching the injection pump. * **Tappet clearance:** Check the tappet clearance and adjust if necessary. For cylinder/piston ring wear or a non-functional injection nozzle, contact the HATZ service station.
K
kwilliamsAug 22, 2025
Why does my Hatz Diesel Engine lose power and emit black smoke?
- J
  Jennifer RodriguezAug 22, 2025
  If your Hatz Diesel Engine loses power, speed, and emits black smoke, the air filter may be dirty. Try cleaning or replacing the air filter. Also, the tappet clearance might not be correct, so you should adjust it. If these steps don't resolve the issue, the injection nozzle might be malfunctioning, and you should contact the HATZ service station.
T
tonya82Aug 25, 2025
What to do if my Hatz Diesel 1B20 Engine shuts off during operation?
- R
  Ralph CummingsAug 25, 2025
  If your Hatz Diesel Engine switches off spontaneously, it could be due to an interrupted fuel supply. Add fuel to the tank. Other potential causes include a clogged fuel filter (change it), a clogged tank vent (ensure sufficient venting), or air in the fuel system (check for air ingress and inspect the bleed valve). For mechanical faults, contact the HATZ service station.
V
Veronica KelleyAug 28, 2025
Why is my Hatz Diesel 1B20 Engine overheating?
- A
  Anthony DavisAug 29, 2025
  If your Hatz Diesel Engine gets very hot and the cylinder head temperature indicator lamp lights up, there might be too much engine oil. Drain the oil to the upper mark on the dipstick. Also, check for contamination in the cooling air guides and clean the cooling air area. Ensure that the air baffle plates are complete and seal well.
C
Cathy ToddAug 31, 2025
How to stop condensate from coming out of my Hatz Diesel Engine exhaust?
- T
  taylor20Aug 31, 2025
  To resolve condensate emerging from the exhaust silencer of your Hatz Diesel Engine, operate the machine at a load of approximately 70% until the exhaust outlet is dry again. This issue typically occurs due to extended operation under no load.
L
laura01Sep 4, 2025
Why does my Hatz Diesel Engine switch off spontaneously during operation?
- W
  William JohnsonSep 4, 2025
  Your Hatz Diesel Engine might be switching off spontaneously due to several fuel-related issues or mechanical faults. Here are some possible causes and solutions: * **Fuel supply interruption:** Add fuel to the tank. * **Empty fuel tank:** Refill the tank with fuel. * **Clogged fuel filter:** Replace the fuel filter. * **Clogged tank vent:** Ensure the tank is adequately vented. * **Air in the fuel system:** Check the fuel system for air ingress and inspect the bleed valve. * **Mechanical faults:** Contact the Hatz service station.
D
deanna52Sep 7, 2025
What to do if my Hatz Diesel Engine gets very hot?
- H
  hicksrobinSep 7, 2025
  If your Hatz Diesel Engine becomes very hot and the cylinder head temperature indicator lamp lights up, consider these potential causes: * **Excessive engine oil:** Drain the engine oil until it reaches the upper mark on the dipstick. * **Inadequate cooling:** Clean the entire area of the cooling air guides to remove any contamination.
C
Carol RobinsonSep 12, 2025
Why does condensate emerge from the exhaust silencer of my Hatz Diesel 1B20 Engine?
- V
  vdaySep 12, 2025
  Condensate emerging from the exhaust silencer of your Hatz Diesel Engine is likely due to operation under no load for an extended period. Operate the machine at a load of approximately 70% until the exhaust outlet is dry again.

Summary

Safety

General Safety Information

Information on working safely, accident prevention, and following instructions.

Safety Notes

Important safety instructions for personal protection and safe operation.

Technical Data

Engine Technical Data

Specifications for engine type, dimensions, oil capacity, and performance.

Transport, Assembly, and Commissioning

Operation and Use

Operation Safety Notes

Essential safety guidelines for operating the machine.

Pre-Operation Tests

Tests to ensure the machine is working properly before starting.

Setting the Speed Control

Starting the Engine

Information on starting options and initial procedures.

Starting with Recoil Start (Cold Weather)

Detailed steps for starting the engine using the recoil starter in cold conditions.

Starting with Electric Starter

Procedure for starting the engine using an electric starter.

Switching Off the Engine

Switching Off (Mechanical)

Switching Off (Electrical)

Refueling the Engine

Checking and Adding Engine Oil

Instructions for checking the engine oil level and topping up.

Checking Engine Oil Level

Step-by-step guide for checking the engine oil level using the dipstick.

Maintenance Procedures

General Maintenance Instructions

Essential safety and procedural guidelines for performing maintenance tasks.

Maintenance Work Overview

Maintenance Plan and Intervals

Changing the Engine Oil

Cleaning the Oil Filter

Checking and Setting Tappet Clearance

Changing the Fuel Filter

Troubleshooting and Faults

Troubleshooting Guide

Common faults, their possible causes, remedies, and related chapters.

Emergency Start Procedure
