1B20 | 1B27 | 1B30 | 1B40 | 1B50

www.HATZ-DIESEL.com

Hat z Diesel

CREATI NG POWER SOLUTI ONS.

OPERATOR’ S MANUAL

Diesel engine

0000 433 802 10 - 01.2013 - 3

Printed in Germany

ENG

Table of Contents

Other manuals for Hatz Diesel 1B50

Original Instruction Book63 pages

Questions and Answers

A
Arthur DavisAug 14, 2025
How to troubleshoot starting issues with my Hatz Diesel Engine?
- P
  patrickpenaAug 14, 2025
  If your Hatz Diesel Engine won't start or hesitates but turns easily, make sure the speed control lever is in the "START" position. Also, check if there is fuel at the injection pump by adding fuel and systematically checking the entire fuel supply. Insufficient compression may be the issue, so check and adjust the tappet clearance if needed. If the temperature is below the start limit, activate the pre glow unit (if equipped). For cylinder/piston ring wear or a non-functional injection nozzle, contact the HATZ service station.
R
Roger BowmanAug 17, 2025
What to do if my Hatz Diesel Engine hesitates or won't start?
- J
  Jeffrey MannAug 18, 2025
  If your Hatz Diesel Engine hesitates or doesn't start but turns easily, here are a few things to check: * **Speed control lever position:** Ensure the speed control lever is in the "START" operating position and the stop pin is not in the STOP position. * **Fuel supply:** Add fuel and systematically check the entire fuel supply system to ensure fuel is reaching the injection pump. * **Tappet clearance:** Check the tappet clearance and adjust if necessary. For cylinder/piston ring wear or a non-functional injection nozzle, contact the HATZ service station.
D
Donna MartinezAug 20, 2025
Why does my Hatz Diesel 1B50 lose power and emit black smoke?
- B
  Brenda GouldAug 21, 2025
  If your Hatz Diesel Engine loses power, speed, and emits black smoke, the air filter may be dirty. Try cleaning or replacing the air filter. Also, the tappet clearance might not be correct, so you should adjust it. If these steps don't resolve the issue, the injection nozzle might be malfunctioning, and you should contact the HATZ service station.
C
clinton06Aug 25, 2025
What to do if my Hatz Diesel Engine shuts off during operation?
- I
  ibishopAug 25, 2025
  If your Hatz Diesel Engine switches off spontaneously, it could be due to an interrupted fuel supply. Add fuel to the tank. Other potential causes include a clogged fuel filter (change it), a clogged tank vent (ensure sufficient venting), or air in the fuel system (check for air ingress and inspect the bleed valve). For mechanical faults, contact the HATZ service station.
T
Teresa PriceAug 27, 2025
Why is my Hatz Diesel 1B50 overheating?
- K
  Kurt HernandezAug 27, 2025
  If your Hatz Diesel Engine gets very hot and the cylinder head temperature indicator lamp lights up, there might be too much engine oil. Drain the oil to the upper mark on the dipstick. Also, check for contamination in the cooling air guides and clean the cooling air area. Ensure that the air baffle plates are complete and seal well.
K
Kristy SantosAug 31, 2025
How to stop condensate from coming out of my Hatz Diesel Engine exhaust?
- J
  jacksonshannonAug 31, 2025
  To resolve condensate emerging from the exhaust silencer of your Hatz Diesel Engine, operate the machine at a load of approximately 70% until the exhaust outlet is dry again. This issue typically occurs due to extended operation under no load.
K
katiesharpSep 3, 2025
Why does my Hatz Diesel 1B50 Engine switch off spontaneously during operation?
- J
  Joyce CrosbySep 3, 2025
  Your Hatz Diesel Engine might be switching off spontaneously due to several fuel-related issues or mechanical faults. Here are some possible causes and solutions: * **Fuel supply interruption:** Add fuel to the tank. * **Empty fuel tank:** Refill the tank with fuel. * **Clogged fuel filter:** Replace the fuel filter. * **Clogged tank vent:** Ensure the tank is adequately vented. * **Air in the fuel system:** Check the fuel system for air ingress and inspect the bleed valve. * **Mechanical faults:** Contact the Hatz service station.
C
Christian BartonSep 6, 2025
What to do if my Hatz Diesel 1B50 Engine gets very hot?
- D
  David ThomasSep 6, 2025
  If your Hatz Diesel Engine becomes very hot and the cylinder head temperature indicator lamp lights up, consider these potential causes: * **Excessive engine oil:** Drain the engine oil until it reaches the upper mark on the dipstick. * **Inadequate cooling:** Clean the entire area of the cooling air guides to remove any contamination.
C
Caitlin MonroeSep 10, 2025
Why does condensate emerge from the exhaust silencer of my Hatz Diesel 1B50 Engine?
- J
  jon90Sep 10, 2025
  Condensate emerging from the exhaust silencer of your Hatz Diesel Engine is likely due to operation under no load for an extended period. Operate the machine at a load of approximately 70% until the exhaust outlet is dry again.

Summary

Notices and Contact Information

Contact Data and Copyright

Provides manufacturer contact details and copyright information for the manual.

General Information about the Manual and Machine

Document Overview and Machine Details

Describes the manual's purpose and the HATZ diesel engine it covers.

Customer Service and Liability Exclusion

Details customer service recommendations and manufacturer liability limitations.

Safety Guidelines for Engine Operation

General Safety Information

Provides essential safety instructions to prevent accidents and damage.

Intended Use and User Obligations

Defines proper engine use, foreseeable misuse, and user responsibilities.

Safety Notes and Symbols Explained

Explains the structure of safety notes and the meaning of signal words and symbols.

Operational Safety Instructions

Details critical safety instructions for safe and reliable engine operation.

Personal Protective Equipment (PPE)

Specifies required PPE such as safety shoes, hearing protection, and gloves.

Machine-Specific Safety Instructions

Covers safety aspects specific to engine operation and maintenance tasks.

Electrical Equipment Safety Precautions

Highlights safety measures when working with the engine's electrical components.

Machine Labels and Warning Signs

Identifies and explains the purpose of various labels on the engine.

Technical Specifications of the Engine

Engine and Fuel Specifications

Details engine types, combustion system, displacement, and fuel requirements.

Engine Oil and Viscosity Recommendations

Specifies suitable engine oils, ACEA/API ratings, and viscosity guidelines.

Engine Design Overview

Identification of Engine Components

Provides a labeled diagram and list of key engine parts and their designations.

Transport, Assembly, and Commissioning

Transport and Assembly Procedures

Guides on safe handling, lifting, and assembly of the engine.

Preparations for Initial Commissioning

Outlines necessary checks and preparations before starting the engine.

Operation and Use of the Engine

General Operation Safety Notes

Highlights critical safety precautions during engine operation.

Pre-Operation Tests and Checks

Lists essential checks to perform before starting the engine for proper function.

Starting the Engine Procedures

Details methods for starting the engine, including recoil and electric start.

Switching Off the Engine

Explains how to safely shut down the engine using mechanical or electrical methods.

Refueling Procedures and Safety

Covers safe refueling practices and fuel type recommendations.

Fluid Level Checks and Adjustments

Instructions for checking water separator and engine oil levels.

Maintenance of the Engine

General Maintenance Guidelines

Provides overall principles and safety rules for performing maintenance.

Maintenance Schedule and Intervals

Defines routine maintenance tasks and their recommended intervals.

Air Intake and Cooling Area Maintenance

Instructions for checking and cleaning air intake areas and cooling components.

Fluid System Maintenance

Procedures for changing engine oil and cleaning/replacing oil and fuel filters.

Tappet Clearance and Exhaust Maintenance

Covers checking tappet clearance and cleaning the exhaust screen.

Oil Bath Filter Maintenance

Steps for cleaning and maintaining the engine's oil bath air filter.

Air Filter Maintenance and Cleaning

Guidance on maintaining dry air filters and cleaning air filter cartridges.

Troubleshooting Engine Faults

Troubleshooting Guide for Common Issues

Lists common faults, their possible causes, and recommended remedies.

Emergency Start Procedures

Details how to activate emergency start mode and its safety implications.

Machine Storage and Disposal

Machine Storage and Disposal Guidelines

Provides instructions for storing the engine long-term and proper disposal methods.

Installation Declaration

Manufacturers Declaration of Incorporation

Official declaration regarding compliance with EC Machinery Directives.

Hatz Diesel 1B50 Specifications

General

Engine Model	1B50
Fuel Type	Diesel
Cooling System	Air-cooled
Compression Ratio	20:1
Fuel System	Direct injection
Lubrication System	Forced lubrication with gear pump
Engine Type	Single-cylinder, 4-stroke diesel engine
Starting System	Electric or Recoil
