Operation and use 2-4L41C, 2-4M41(Z), 4L42C, 4M42
44
HATZ
Manual
Preparation
Step Activity
1 Carry out start preparations (see the chapter 7.3 Start prepara-
tion, page 38).
2 Move the speed control lever into position "Start" (see the chap-
ter Setting the speed control).
3 Move all decompression levers to position "1".
▪ 1 lever for two cylinder engine
▪ 3 levers for three cylinder engine
▪ 4 levers for four cylinder engine
NOTICE
Only operate the decompression lever while the engine is at a
standstill and observe the sense of rotation
▪ Only turn the decompression lever in the direction of the ar-
row.
▪ Exception: The lever can be turned directly back from posi-
tion "1" to "0".
▪ Position "1" is the continuous decompression setting.
Procedure
Step Activity
1 Insert the crankhandle into the guide sleeve (4).
2 Assume the correct position.
3 Grasp the handle bar with both hands.
4 Crank the engine until the crank resistance becomes markedly
less.
