2-4L41C, 2-4M41(Z), 4L42C, 4M42 Operation and use
HATZ
47Manual
Step Activity
1 Setting the decompression lever:
▪ Two cylinder engine 2M41.
Turn the lever to position "2".
▪ Three cylinder engine 3M41.
Turn the levers of the 1st and 3rd cylinders to position "2".
Turn the lever of the 2nd cylinder to position "3".
▪ Four cylinder engine 4M41.
Turn the levers of the 1st, 3rd and 4th cylinders to position "2".
Turn the lever of the 2nd cylinder to position "3".
Starting the engine with an anti-kick crank handle
Step Activity
1 Assume the correct position.
2 Grasp the handle bar with both hands.
3 First turn the crank handle slowly until the drive dog and the en-
gagement mechanism of the crank handle engage.
4 Turn the crank handle forcefully with increasing speed. When
the decompression lever engages in the "0" position (compres-
sion), the highest possible speed must be reached.
5 As soon as the engine starts, pull the crank handle out of the
guide sleeve.
NOTICE
i
If recoil occurs during the starting process, the crank arm/drive
dog linkage releases via the handle bar due to the short reverse
rotation.
Starting the engine with a crank handle without recoil damping
Step Activity
1 Assume the correct position.
2 Grasp the handle bar (1) with both hands.
3 Slowly turn the crank handle until the drive dog (3) engages.
4 Turn the crank handle forcefully with increasing speed. When
the decompression lever engages in the "0" position (compres-
sion), the highest possible speed must be reached.
