31
Do not move through neutral without pausing.
Any handle movement automatically causes engine speed to increase.
Reminder:
In case of overload, the platform up/down functions are disabled.
WARNING.
In the final stage of lowering, an "anti-shear" system prevents
any risk of shear when the scissors are stowed.
The platform lower function is controlled mainly by the handle, down to a position where the minimum inter-
arm gap is 50 mm. This prevents shear risk. To continue lowering:
• release the handle,
• ensure there are no persons (or obstructions) near the machine,
• press button (item 4) until the platform is fully down. During this time, the buzzer continues to sound for
safety purposes.
Stabilisation (option): see § 4.10
Changeover to electrical power (bi-energy option):
• Stop engine using procedure described above.
• Set the fuel select switch (item 8) to electric. The green power-on light should come on.
Return to diesel (bi-energy option)
• Press the emergency stop button.
• Quarter-turn the emergency stop button to unlock.
• Move the fuel select switch to diesel.
• Push down start button and release when engine starts running. The green power-on light should come
on.
4.6. BATTERY CHARGE TESTER / HOUR-METER (BI-ENERGY).
This device (item 7, photo 2) contains the following:
• Battery charge indicator
• Hour-meter
• Rest
The tester runs on a lithium battery with a life span of over 15 years.
The tester is protected by a fuse, A 2 A - FU1.
4.6.1. Battery charge indicator.
The battery charge indicator is displayed by 10 LEDs: 2 red, 3 orange, 5 green.
When the battery is properly charged, the far-right green diode lights up. For this, the charger must be
unplugged and charging complete.
When the battery discharges, the diodes light up progressively from right to left, one by one.
When the battery is 70% discharged, the first red diode flashes. Battery recharging is advisable.
When the battery is 80% discharged, both red diodes flash. The cut-out limit has been reached, and lift is
interrupted. Now the batteries must be recharged.
4.6.2. Hour-Meter.
This runs when the motor pump is running: the "egg timer" flashes.
4.6.3. Reset.
This happens when the battery is correctly recharged.
