TABLE OF CONTENTS

PAGE PAGE

Safety rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Speciﬁcations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Parts illustration and list . . . . . . . . . . . . . . . . . . . . . . 29-31

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

For your own safety, read all of the rules and precautions before operating tool.

CAUTION:

Always follow proper operating procedures as deﬁned in this manual even if you are familiar with use of this or similar

tools. Remember that being careless for even a fraction of a second can result in severe personal injury.

SAFETY RULES

WARNING

SPECIFICATIONS

Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/2 HP

Depth of throat at 90º . . . . . . . . . . . . . . . . 12” (304.8 mm)

Maximum depth of cut at 90º . . . . . . . . . . . . 7” (177.8 mm)

Maximum depth of cut at 45º . . . . . . . . . 4-1/2” (114.3 mm)

Table size . . . . . . . . . . . . . . 13” x 13” (330.2 x 330.2 mm)

Table tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0º to 45º

Wheel diameter . . . . . . . . . . . . . . . . . . 12-1/2” (317.5 mm)

Blade length . . . . . . . . . . . . . . . . . . . . . . . . . 90.55” (2.3 m)

Blade width . . . . . . . . . . . . . . . 1/8” - 1/2” (3.18 - 12.7 mm)

Blade speed . . . . . . . . . . . . . . . . . . 1620 FPM / 3340 FPM

Overall dimensions . . . . . . . . . . . 24-5/8” x 17-3/16” x 42”

. . . . . . . . . . . . . . . . . . 625.48 x 436.56 x 1066.8 mm

Net weight . . . . . . . . . . . . . . . . . . . . . . . . . .84 lb (38.1 kg)
