– 2 –
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
WARNING
!
2010/10
MOTOR SAW
Type
Universal Table size 22 in. x 19-3/4 in.
(559 mm x 502 mm)
Amps 15
Rip capacity
24 in. (610 mm)
Right & Left
Voltage 120 Blade diameter size 10 in. (254 mm)
Hz 60 Blade arbour 5/8 in. (15.9 mm)
RPM (no load) 5000 CUTTING CAPACITY
Overload protection YES Maximum cut depth @ 90° 3 in.(76 mm)
MITRE GAUGE YES Maximum cut depth @ 45° 2-1/2 in.(64 mm)
RIP FENCE YES Maximum diameter dado 6 in. (Stackable only)
Maximum dado cut width 1/2 in.(13 mm)
Printed in Taiwan
SECTION PAGE SECTION PAGE
Product specifications...........................................
2
Glossary of terms.........................................
12
Safety guidelines - definitions..............................
3
Assembly and sdjustments...........................
13
Power tool safety.................................................
4
Operation......................................................
22
Table saw safety..................................................
5
Maintenance.................................................
27
Electrical requirements and safety.......................
7
Push stick pattern.........................................
29
Accessories and attachments.............................
8
Troubleshooting guide..................................
30
Tools needed for assembly..................................
8
Warranty.......................................................
31
Carton contents....................................................
9
Parts list.......................................................
32
Know your table saw...........................................
11
To avoid electrical hazards, fire hazards or damage to the tool, use proper circuit protection. Use a seperate electrical
circuit for your tools. To avoid electrical hazards, fire hazards or damage to the table saw, use proper circuit protection.
This table saw is wired at the factory for 120 Volt operation. It must be connected to a 120 Volt / 15 Ampere time delay
fuse or circuit breaker. To avoid shock or fire, replace power cord immediately if it is worn, cut or damaged in any way.
